- Xiamen Zhizhujing Electronic Co., Ltd
-
Zaozhuang, Shandong, China
- Main products: Precision Torque Wrench
Home > Products > Precision Torque Wrench > 600 - 3000 Nm tools ASME B107.14m automotive Ratchet Torque Wrenches for bicycle
600 - 3000 Nm tools ASME B107.14m automotive Ratchet Torque Wrenches for bicycle
Negotiable
/ Piece
1 Piece(Min.Order)
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
precision 1/2\" 65 - 335 Nm click stop sturtevant richmont cdi Torque Wrench
-
giant Setting Click calibrate Torque Wrench, Micrometer Scale, Knurled Grip
-
18-180lbf.in Digital 1% Precision Torque Wrench with USB Interface for Space flight
-
0.1, 0.25, 0.5 N.m Automobile Precision Torque Wrenches for Machine Tool Building
-
1%, 3% Manual Precision Torque Wrenches of high precision phonetic torque tools
-
Precision 1%, 3% adjustable hex Industrial Torque Wrench for Automobile, Railway, Bridge
Product Details
| Brand Name | Zhizhujing | Place of Origin | China | |
| Model Number | CM series |
Product Description
600 - 3000 Nm tools central automotive Ratchet Torque Wrenches for bicycle
45 Tooth Ratchet Torque Wrench
4% CW accuracy
Tested to over 50,000 cycles
Soft TPR grip
Calibration report included
Torque wrench
*Double window scale,plastic grip,high precision,resulting in fast and efficient operation.
*The 45-tooth reversible ratchet head for both clockwise and counterclockwise operation.
*4% accuracy in clockwise direction exceeds international specifications.
*Ergonomic soft TPR grips are comfortable to use.
*Unique, stay-in-place,Lock Ring makes adjustments easier and secures selected torque from accidental change.
*Metric scale with fine increments and reference English scales are easy to read and set.
*The identity code marked on each wrench makes it possible to keep accurate records.
Metric Unit
|
Part Code |
Drive | Torque Range | Length | Width | Weight | |
| N.m | Lb.ft | mm | mm | kg | ||
| CM1012 | 1/4\" | 2.5-12 | 20-105* | 285 | 38 | 0.54 |
| CM1020 | 1/4\" | 4.0-20 | 30-180* | 285 | 38 | 0.54 |
| CM2030 | 3/8\" | 6.0-30 | 50-250* | 313 | 38 | 0.68 |
| CM3030 | 1/2\" | 6.0-30 | 50-250* | 313 | 38 | 0.68 |
| CM2060 | 3/8\" | 10-60 | 9-45 | 383 | 38 | 0.82 |
| CM3060 | 1/2\" | 10-60 | 9-45 | 383 | 38 | 0.82 |
| CM2125 | 3/8\" | 25-125 | 20-90 | 438 | 38 | 0.90 |
| CM3125 | 1/2\" | 25-125 | 20-90 | 438 | 38 | 0.90 |
| CM3200 | 1/2\" | 40-200 | 30-150 | 463 | 40 | 1.02 |
| CM3335 | 1/2\" | 65-335 | 50-250 | 523 | 40 | 1.16 |
| CM4335 | 3/4\" | 65-335 | 50-250 | 523 | 40 | 1.20 |
| CM3335L | 1/2\" | 65-335 | 50-250 | 700 | 40 | 1.95 |
| CM4335L | 3/4\" | 65-335 | 50-250 | 700 | 40 | 2.00 |
| CM4400 | 3/4\" | 80-400 | 60-300 | 700 | 57 | 2.75 |
| CM4500S | 3/4\" | 100-500 | 80-400 | 700 | 57 | 2.75 |
| CM4500 | 3/4\" | 100-500 | 80-400 | 840 | 60 | 4.04 |
| CM4800 | 3/4\" | 160-800 | 120-600 | 1040 | 60 | 4.93 |
| CM5800 | 1\" |
