Help Center160 KN EMH 23-16 C-frame High Performance Inclinable Power Press Machine
Related Products
-
460mm F-B EMM Mechanical Power Metal Press Punching Stamping MachineNegotiableMOQ: 1 Set -
430mm L-R EMH C-frame Inclinable High Speed Mechanical Power Presses MachineNegotiableMOQ: 1 Kilogram
-
EMM23-25 C-frame Inclinable Hydraulic Punching Stamping Power Bearing Presses MachineNegotiableMOQ: 1 Set
-
1070mm F B EMS C-style Deep-throat Mechanical Power Press Hydraulic Bending MachineNegotiableMOQ: 1 Kilogram
-
EMM23-40 C-frame Mechanical Power Bale Clicker Bliss Press Machine Hydraulic EquipmentNegotiableMOQ: 1 Piece
Certification:CE,ISO,SGS,FDA
stable precision
slider with mechanical overload protection device,safe, raliable
has a long service life
Technical Data:
|
Specifications |
Unit |
EMH23-16 |
|
|
Nominal Capacity (Pe) |
KN |
160 |
|
|
Nominal Stoke(Sp) |
mm |
2 |
|
|
Nominal Stoke(S) |
mm |
55 |
|
|
Slide Strokes Pre Minute(n) |
times/min |
125 |
|
|
Maximum Die Set Height(H2) |
mm |
220 |
|
|
Die Height Adjustment(t) |
mm |
45 |
|
|
Throat Depth(C1) |
mm |
160 |
|
|
Distance Between Uprights(d1) |
mm |
220 |
|
|
Slide Bottom Size |
L×R(a) |
mm |
200 |
|
F×B(b) |
mm |
180 |
|
|
Stem hole Size |
Dia(d) |
mm |
40 |
|
Depth(l) |
mm |
60 |
|
|
|
L×R(C) |
mm |
450 |
|
F×B(D) |
mm |
300 |
|
|
Blanking hole diameter(Φ) |
mm |
100 |
|
|
Bolster Thickness(H3) |
mm |
40 |
|
|
Max. Angle Of Inclination(2) |
35 |
||
|
Bolster Surface Height(H1) |
mm |
750 |
|
|
Overall Dimensions |
F×B(A) |
mm |
1200 |
|
L×R(B) |
mm |
1050 |
|
|
H |
mm |
1960 |
|
|
Distance Between Foundation Bolts |
F×B(a’) |
mm |
780 |
|
L×R(b’) |
mm |
450 |
|
|
Motor Power |
