UNIVERSAL 4796A SMTpart

Pg 11-12: Index, added tables for dual head and single head machine behavior.
Table of Contents
Introduction ................................................................................................................................................................... 1
The Window ........................................................................................................................................................ 1
Steps .............................................................................................................................................................................. 3
Alter (sequencing machines only) ....................................................................................................................... 3
Move .................................................................................................................................................................... 4
Bypass .................................................................................................................................................................. 4
No Continuity ...................................................................................................................................................... 5
Ignore Continuity ................................................................................................................................................ 5
Enable .................................................................................................................................................................. 6
Sort ....................................................................................................................................................................... 7
Select All .............................................................................................................................................................. 9
DeSelect All ......................................................................................................................................................... 9
Select Invalid ....................................................................................................................................................... 9
Recover From Invalid Step ........................................................................................................................ 9
Print .................................................................................................................................................................... 10
Special Steps ............................................................................................................................................................... 10
Delete ................................................................................................................................................................. 10
Add..................................................................................................................................................................... 11
Index......................................................................................................................................................... 11
Index to Transfer ...................................................................................................................................... 13
Park ........................................................................................................................................................... 13
Feed-Only ................................................................................................................................................. 14
Clinch Down ............................................................................................................................................ 14
Transfer Steps ........................................................................................................................................... 15
Bad Board/Circuit Reject (single head machines only) .......................................................................... 15
Board/Circuit Error Correction ................................................................................................................ 20
Change Correction Locations ........................................................................................................ 26
Auto Miss Mark (dual head machines only) ............................................................................................ 27
Checkgap (axial machines only) ............................................................................................................. 30
Search .......................................................................................................................................................................... 31
Search and Replace Controls ............................................................................................................................. 33
Options ........................................................................................................................................................................ 34
Insert .................................................................................................................................................................. 34
Sort ..................................................................................................................................................................... 35
Overview ............................................................................................................................................................ 35
Exit .............................................................................................................................................................................. 36
Changes To This Revision .......................................................................................................................................... 37
Steps StepsStepsSteps Steps
Steps
47139810 Rev. -
01-00tln
Steps StepsStepsSteps Steps
Steps
47139811 Rev. -
06-00tln
Table of Contents
Introduction ................................................................................................................................................................... 1
The Window ........................................................................................................................................................ 1

>ĝk /r
ĝ2ĝ09eight=19 style='height:14.25pt'> A second pulldown menu is displayed.  .  Select Above to move the highlighted steps above a selected step in the insertion order. All subsequent steps numbers are adjusted accordingly.  .  Select Below to move the highlighted steps below a selected step in the insertion order. This is the default choice. All subsequent steps numbers are adjusted accordingly.  A checkmark visible in front of the menu option indicates the choice. Once an insert choice is selected, it does not have to be selected again except to change the choice. The choice remains selected until the Product Editor is closed.  Sort  Use the Sort option to define the order of any selected sort of the steps list.    To define the sort choice:  1. From the Steps window:  Options > Sort  A second pulldown menu is displayed.  .  Select Ascending to perform any selected sort of the steps list in ascending order. This is the default choice.  .  Select Descending to perform any select sort of the steps list in descending order.  A checkmark visible in front of the menu option indicates the choice. Once the sort choice is selected, it does not have to be selected again except to change the choice. The choice remains selected until the Steps window is closed.  Overview    Use the Overview option to display a thumbnail graphical overview of the entire steps list in the far-right side of the window. This features shows where the steps currently displayed are located in relation to the rest of the pattern. A checkmark visible in front of the menu option indicates that the Overview option is active.  To display the graphical overview:  1. From the Steps window:  Options > Overview  The Steps window with the overview shown is displayed.  Note the thumbnail overview on the right side of the window. The overview is especially useful if the pattern is long.  Exit  Select Exit to close the Steps window.  Changes To This Revision  New part number.
