Triangle Fence

Panel's Specification
1. Wire diameter: 5.0mm, 4.5mm, 4.0mm, 5.5mm, 6.0mm, 3.5mm, 4.8mm and others.
2. Mesh size: 200x 50mm, 100x 50mm, 200 x55mm, 100x 55mm, 150x 50mm, 150 x55mm, 120x 50mm, 120x 55mm, and others
3. Length: 2500mm, 2255mm, 2000mm, 3000mm
4. Height: 630mm, 830mm, 1030mm, 1230mm, 1530mm, 1730mm, 1630mm, 1830mm, 1930mm, 2030mm, 2230mm, 2430mm

Post
Hot-dipped galvanized and powers coating
1. Size: 60x 60x 1.5mm, 60 x60x 2.0mm, 60x 40 x2.0mm and others
2. Height: 300-700mm more than panel's height, or same as the panel and with the bottom base.
3. Colors choosed: All RAL colors
RAL6005 GREEN, RAL9010 WHITE, RAL 7016, RAL7030, RAL 9005 BLACK, RAL 9006, RAL 8017 BROWN and others.
4. Galvanized weight: About 60G/M2 for panel, about 130G/M2 for post.
5. PVC coating thickness: 400-500 microns
Powders sprayed coating: 100-140 microns
Fastenings:

The panels and posts are jointed together with bolts or rivets, using the steel flat bar, or special steel clamps, all nuts are self-locking. This also can be designed as the special clients requests.

Structure:

The partion fencing, Welded with cold-drawn low carbon steel wire, is fixed with joint accessories and poles.
Characteristics:

1.The products are anti-corrosive, resisting to acid and alkali, aging-proof, beautiful and practical.
2. Special design style makes the fence more fashionable.
3. Once installed, it is difficult to knock down.
4. Many colors are available.
5. It is convenient to install, which save your time and cost.
5. Beautiful and practical..
6. It can last more than 10 years, during which time it wouldn’t rust and lost print.

Application:

Dirickk Axis Fence is widely used for partition and protection of construction of cities, including gardens, lawn, zoos, pools and lakes, roads and uptowns, for protection and decoration of hotels, restaurants, and supermarkets.

 Fittings:

1metal claw

2Metal clamp

3Anti theftproof bolts&nuts

4washer

5plastic clips
