Description
Network Cable Tester is a powerful special tool to prevent and solve cable installation problem, which can be used to verify any speech and data cable installation procedure. Its main functions are: cable connection sequence, length testing, and determine any open, short circuit, jumper or cross-talk interference.
Product features
1. One person enough to locate the wire or connection error
2. Checks wiring error in 5E, 6E, coaxial and telephone line such as open circuit, short circuit, jumper wire, reverse connection or cross-talk interference
3. Measures cable length and determines the distance of open circuit and short circuit
4. Dynamically calibrates cable length and makes length measurement as accurate as 95%
5. Simple and easy use, big screen to display test clear
6. Portable unit with long battery life (wait-case 50 hours)
7. Automatically time-delay shut off
8. Self-checking function and automatically compensates any change in battery capacity or ambient temperature
Technical parameters
|
Overall Dimension |
180×80×40mm |
|
Power Supply |
4×1.5V Size AA batteries |
|
Display |
Special 4×16 character big screen LCD lattice (valid visual field 61.6×25.5 mm) |
|
Type of Test Cable |
STP/UTP twin twisted cable, coaxial cable, telephone line |
|
Working Ambient Temperature |
-10~+60 |
|
Tester Port
|
Tester RJ45 master port(M), tester LOOPBACK RJ45 port(L), far-end recognizer RJ45 port(R). The extra BNC and RJ11 converters are used to measure and check the continuity of coaxial cable and telephone line. |
|
Length Measurement of Twin Twisted Cable |
Scope: 350M(3~200ft) Calibration accuracy:3%(±0.5Mor±.5ft) (calibrating cable≥5M) Shipment accuracy :5%(±0.5M or ±1.5ft).(AMP,AT& T Class 5 cable) Display: M or ft |
|
Length Calibration
|
User can set calibration factor by himself with a given length cable. The length of cable should be more than 5M |
|
Wire Sequence and Locating Cable Error |
Check errors such as open, short circuit, reverse connection, crossover or cross-talk interference. |
|
Automatic Time-delay Shut Off Time |
The tester will be on standby for 30 minutes. |
