Customizable Layout IP65 Waterproof Rugged Dust-proof Metal Industrial Keyboard
Negotiable
MOQ: 1 Pole (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
zhuobo
Place of Origin:
China
Model Number:
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Liquid-proof 65 Backlit Keys Panel Mount Waterproof Rugged Illuminated Metal KeyboardNegotiableMOQ: 1 Piece -
Waterproof Illuminated Metal Backlight Keyboard With LED Back-lit Keys MKB-64B-TB-BLNegotiableMOQ: 1 Piece
-
OEM Robust Construction High Resistance Against Vandalism Illuminated Metal KeyboardNegotiableMOQ: 1 Piece
-
65 LED Dust-proof and Liquid-proof Low-lit Environments Illuminated Metal KeyboardNegotiableMOQ: 1 Piece
-
OEM / ODM White / Black Super Slim Bluetooth Wireless Illuminated Metal KeyboardNegotiableMOQ: 1 Unit
Brand Name
zhuobo
Place of Origin
China
Delivery Time:7-15 days
Certification:CE/FCC
2) with integrated touchpad
3) Panel mount, installing from behind
4) Protruding full travel(2.0mm)keys with laser-etched legend, excellent tactile feedback
5) Specially designed to operate in harsh and low-lit environments
6) Robust construction, high resistance against vandalism
7) Dust-proof and liquid-proof, meet IP65 requirement after properly mounted
8) PS/2 or USB interface for option 9) Customizable layout upon customer\'s request
- Current rating: 20 mA
- Interface: USB or PS2
- EMC compliant.
Emission: EN 50081-1
Immunity: EN 50082-1
- FCC: Part 15, class B - Safety: EN 60950, CE compliant
- Storage temperature: - 40º C to + 80º C
- Saline mist: 96 hours, IEC 60512-6
- Damp heat test at + 40º C: 21 days, IEC 60512-6 - Dry heat test at + 85º C: 10 days, IEC 60512-6
- Key travel: 2.0mm
- Lifetime (cycles): Min 5, 000, 000 actuations
- Sealing protection: IP65/NEMA4X from the front
- Vibration resistance: 5 Hz - 200 Hz, IEC 60512-4 - Shock resistance: 3 axis 150 m/s² - 11 ms, IEC 60512-4
- Current rating (active mode): 17 mA
- Interface: PS2 or USB
- X/Y position sensing resolution: 40 counts/mm
- X/Y position reporting: Relative - Tracking speed: Maximum 1, 016 m/sec
- Dimension: Front panel: 400.0x124.0x22.2mm
Certification:CE/FCC
Customizable layout IP65 waterproof rugged Dust-proof metal industrial keyboard
1,Vandal-proof LED backlight metal keyboard with touchpad
2,Dust/waterproof,IP65 rate
3,65 illuminated keys
4.Panel mount
Key Features:
1) 65 LED individually backlit/backlight/illuminated keys2) with integrated touchpad
3) Panel mount, installing from behind
4) Protruding full travel(2.0mm)keys with laser-etched legend, excellent tactile feedback
5) Specially designed to operate in harsh and low-lit environments
6) Robust construction, high resistance against vandalism
7) Dust-proof and liquid-proof, meet IP65 requirement after properly mounted
8) PS/2 or USB interface for option 9) Customizable layout upon customer\'s request
Specifications:
Material
- Front panel: Brushed stainless steel
- Keys:High temperature-resistant polycarbonate
- Back panel: Aluminum alloy
Electrical Data
- Current rating: 20 mA
- Interface: USB or PS2
- EMC compliant.
Emission: EN 50081-1
Immunity: EN 50082-1
- FCC: Part 15, class B - Safety: EN 60950, CE compliant
Environmental Characteristics
- Storage temperature: - 40º C to + 80º C
- Saline mist: 96 hours, IEC 60512-6
- Damp heat test at + 40º C: 21 days, IEC 60512-6 - Dry heat test at + 85º C: 10 days, IEC 60512-6
Mechanical Data
- Actuation force for key:120±15g- Key travel: 2.0mm
- Lifetime (cycles): Min 5, 000, 000 actuations
- Sealing protection: IP65/NEMA4X from the front
- Vibration resistance: 5 Hz - 200 Hz, IEC 60512-4 - Shock resistance: 3 axis 150 m/s² - 11 ms, IEC 60512-4
Touchpad
- Power supply voltage: 5 VDC ± 10%- Current rating (active mode): 17 mA
- Interface: PS2 or USB
- X/Y position sensing resolution: 40 counts/mm
- X/Y position reporting: Relative - Tracking speed: Maximum 1, 016 m/sec
Compatible Operation system
- PS2: Win NT4, 98SE, 98ME, 2000, XP - USB: Win 98SE, 98ME, 2000, XP, Mac OS9 / OSX
Color
Keycap:black,grey or silver
Backlight:blue,green or red
Weight and Dimension
- Dimension: Front panel: 400.0x124.0x22.2mm
