Custom Roof Cladding Metal Roll Forming Machine With 13 - 20 Forming Station

A). Main Specification of Roof Cladding Roll Forming Machine:

Material thickness: 0.3-0.8mm Material width: depend on customer’s requirement Decoiler Type: manual or automatical type ( depend on customer’s requirement ) Weight Capacity Of Decoiler: 5 Ton Main Motor Power: 5.5 Kw Hydraulic Motor Power: 3 Kw Forming Station: 13-20 ( depend on profile drawing ) Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface. Main Axis Material: High grade 45#, quenched and heat treatment. Axis Diameter: ¢ 76mm Working Speed: 0-15 m/min Transporting Type: Chain Transmission Heat Treatment of Cutting Blade: HRC 50-60 Type of Cutting: Hydraulic cutting Material Of Cutting Blade: C r 12 Heat Treatment of Cutting Blade: HRC 50-60 Machine Frame stand: Welded structural steel Thickmess of Fame Steel: 18mm Electrical Control: PLC Frequency Control System with touch screen PLC: PANASONIC Brand Encoder: OMRON Brand Transducer: PANASONIC Brand Machine Weight: about 5 Ton

B).  Main Components:

Decoiler ---------------------------------------------- 1 Unit Feeding guide -------------------------------------- 1 Unit main roll forming machine ----------------------- 1 Unit Hydraulic cutting device -------------------------- 1 Unit Hydraulic Station ----------------------------------- 1 Unit PLC computer control ---------------------------- 1 Unit Output table ------------------------------------------ 1 Unit

C). Work Flowing:

Decoiler --- Fedding Guide --- Roll Forming --- Cut-to-length --- Run out table

Applications:

Roof cladding, roof cladding sheet, roof cladding panel, metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding

Competitive Advantage:

High Quality Reasonable Price Good after Service 1 Year Warranty More Than 10 Years Experience
