Carbon Steel 15KW 1.5 - 3.0mm Material Thickness Top Hat Channel Cold Roll Forming Machine

Delivery Time:55-65 working days
Certification:CE

Carbon Steel 15KW 1.5 - 3.0mm Material Thickness Top Hat Channel Cold Roll Forming Machine

A). Work Flowing:

Decoiler --- Fedding & Leveling --- Punching --- Roll Forming --- Cut-to-length --- Run out table

B). Main Specification of Top Hat Channel Roll Forming Machine:

Material: GI, Carbon steel Material thickness: 1.5-3.0mm Main power: 15KW Machine diameter: about 11500x1500x1300mm ( LXWXH ) Weight of machine: about 10 Ton Main Technical Specification: Decoiler: Manual or hydraulic decoiler ( customer can choose ) Weight capacity of decoiler: 5 Ton Forming station: 18 Principle axis: 75mm diameter Forming speed: 0-15m/min Drive type: 1.5\' chain transmission Roller material: GCr15 steel, quenched  and heated process Main power: 15KW Hydraulic power: 7.5KW Electrical Control: PLC Frequency Control System with touch screen PLC: PANASONIC Brand Encoder: OMRON Brand Transducer: PANASONIC Brand

C).  Main Components:

Decoiler ---------------------------------------------- 1 Unit Feeding & Leveling -------------------------------- 1 Unit Hydraulic punching device ----------------------- 1 Unit Main roll forming machine ------------------------ 1 Unit Hydraulic cutting device -------------------------- 1 Unit Hydraulic Station ----------------------------------- 1 Unit PLC computer control ----------------------------- 1 Unit Output table ----------------------------------------- 1 Unit

Applications:

Top Hat Channel, Furring Channel, Hat Channel, Ridge Channel, Top Furring Channel...

Competitive Advantage:

High Quality Reasonable Price Good after Service 1 Year Warranty More Than 10 Years Experience
