High Temperature Resistant Yellow 99% Alumina / AL2O3 Ceramic Tubes Wear Parts

High Temperature Resistant Yellow 99% Alumina / AL2O3 Ceramic Tubes Wear Parts thumbnail-1
High Temperature Resistant Yellow 99% Alumina / AL2O3 Ceramic Tubes Wear Parts photo-1
Negotiable MOQ: 1 Metric Ton (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
FFTC
Place of Origin:
China
Model Number:
Contact Supplier Request Quote Chat Now
Yixing Feifan Ceramics Co.Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name FFTC
Place of Origin China
Delivery Time:Depends on the quantity, always in a month.
Certification:ROHS

High Temperature Resistant Yellow 99% Alumina / AL2O3 Ceramic Tubes Wear Parts

Description:

1. Material: 99% AL2O3 (Cr/Mn)

2. Method of molding: Thermal casting/dry press/extrusion

3. Color:yellow

4. Sintering temperature: 1750℃

5. Surface finish: Ra0.4&simRa0.8&mum

6. Packing: Pack with carton and ship with wooden case

7. Produce products according to molds or drawings provided by the client and quote according the data of

    the products

8. The mould fee of the non-standard products: According the quotation of product.

Applications:

Our products can be used in mechanical,electronics,chemical,textile,aeronautic and other fields.

Specifications:

95%,99%,99.7% Al2O3 Material Parameters:

Item

Test Condition

Unit Symbol

95%Alumina

ceramics

99%Alumina

ceramics

99.7%Alumina

ceramics

The main chemical ingredient

Al2O3

Al2O3

Al2O3

Bulk Density

g/cm3

3.6

3.89

3.96

Maximum Use Temperature

1450℃

1600℃

1650℃

Water absorption

%

0

0

0

ROHS Hardness

≥85

≥89

≥89

Flexural strength

20° C

MPa (psi x 103)

358 (52)

550

550

Compressive Strength

20° C

MPa (psi x 103)

2068 (300)

2600(377)

2600(377)

Fracture Toughness

K(I c)

Mpa m1/2

4-5

5.6

6

Coefficient of

thermal expansion

25-1000° C

1X 10-6/°C

7.6

7.9

8.2

Coefficient of

thermal conductivity

20° C

W/m °K

16

30.0

30.4

Thermal Shock Resistance

Tc

°C

250

200

200

Dielectricity constant

1MHz.25℃

9

9.7

9.7

Dielectric strength

ac-kV/mm (ac V/mil)

8.3 (210)

8.7 (220)
