Hydraulic Press for Expanding Used Carbon Steel Pipe

Hydraulic Press for Expanding Used Carbon Steel Pipe thumbnail-1
Hydraulic Press for Expanding Used Carbon Steel Pipe thumbnail-2
Hydraulic Press for Expanding Used Carbon Steel Pipe thumbnail-3
Hydraulic Press for Expanding Used Carbon Steel Pipe photo-1
Hydraulic Press for Expanding Used Carbon Steel Pipe photo-2
Hydraulic Press for Expanding Used Carbon Steel Pipe photo-3
US$ 30000 - 30000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Fengliyuan
Place of Origin:
China
Model Number:
YKG-159
Contact Supplier Request Quote Chat Now
Hebei Yanshan Fengliyuan Pipe Fittings Equipment Manufacture Co.,Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Fengliyuan
Place of Origin China
Model Number YKG-159

Working ability

Can expand 325*16mm carbon steel pipe into the max Ф630x16mm , max length be feed 12.5m

The Main Technical Parameters of The Pipe Expanding Machine

1. The oil cylinder: Ф 300mm,the rod：Ф 230mm，the effective trip: 6.5m,  pressure：21Mpa,2 bars

The maximum thrust of the 2 cylinders: 300 tons;  The normal speed: 0—2500px/min ,

The max backward speed: 7500px/min.

2. The pump station：

63scy-plunger pump :2 set, 18.5KW  Motor:  2 sets (the main working pump)

PV2R13-16-94 double vanes pump: 1 set, 15KW motor: 1set (for fast moving forward and returning,etc)

3. The hydraulic valve is integrated oil rout, hydraulic black fork gate, automatic loading.

4. The frame for the main engine: 25# channel steel, welded  with 43kg steel rail

5. The panel for the main engine: welded with 25-30mm medium plate

6. distribution cabinets, operation box 1 set

7. Intermediate-frequency power (power 600KW  380v、220v、50Hz)
