Help CenterFront Loader/pay Loader ZL08F
Related Products
1.8.25-16 ultra-wide tyres
2.CHANGCHAI L28 single-cylinder engine
3.4-wheel drive
4.2 forward 1 reverse shifts
Wheel loader ZL08F is widely used in construction works, public works, urban and rural parks, highway and transportation, station and wharf, and irrigation and water conservancy, as well as various coal pits, limekiln, coal yard, sand and stone quarry, cement mill, etc. It is especially applicable in narrow sites to shovel and load or move earth, sand and stone, coal cinder, lime, fertilizer, trash and other bulk materials. This mini wheel loader can be used together with various trucks, tractors farm vehicles and construction machineries (sand mixer, pug mill), etc.
Features of ZL08F wheel loader:
1. Using 8.25-16 ultra-wide tyres to increase the stability of the whole machine;
2. Running system adopts mechanical drive, and the power transmission mode adopts belt transmission ;
3. Power system adopts CHANGCHAI L28 single-cylinder engine to make the machine energy saving and environmentally friendly with high working efficiency;
4. 4-wheel drive and fully hydraulic steering make this mini wheel loader light and flexible;
5. The gear shift of this small wheel loader has 2 forward and 1 reverse shifts with high and low speed;
6. This compact wheel loader can be equipped with optional quick hitch (quick coupler) , and this quick hitch enables this compact wheel loader to change quickly among multiple attachments, such as hay grapple, grass grab, log grab, timber grapple, pallet fork, bale grapple, four-in-one bucket, straight snow blade, V-shaped snow blade, snow bucket, drum grab and barrel grapple, etc
Performance
| Rated Load | 800 kg |
| Total Weight | 2400 kg |
| Rated Bucket Capacity | 0.3 m3 |
| Max. Tractive Force | 28 KN |
| Max. Breakout Force | ≥ 21 KN |
| Max. Gradeability | 38° |
| Dumping Height | 2680 mm |
| Dumping Reach | 900 mm |
| Raising Time | ≤ 4.0 s |
| Total Cycle Time | ≤ 9.0 s |
| Overall Dimensions (L x W x H) | 4800*1640*2550 mm |
| Min. Turning Radius | 3000 mm |
Engine
| Model | CHANGCHAI L28 |
| Type | Single-cylinder, Horizontal, Water-cooled Evaporative, Four-stroke Engine |
| Rated Power | 20 kw |
| Rated Speed | 2200 rpm |
| Min. Fuel Consumption Ratio | ≤ 244.8 g/kw·h |
Transmission
| Mode | Mechanical Shift |
| Gear Shift | 2 Forward, 1 Reverse, High & Low Speed |
| Max. Speed | 25 km/h |
Drive Axle
| Model of Axle | 50 Drive Axle |
| Wheel Tread | 1330 mm |
| Wheel Base | 2130 mm |
Drive
| Mode | 4-wheel Drive |
Hydraulic System
| System Working Pressure | 16 Pa |
| Fuel Tank Capacity | 60 L |
Brake System
| Service Brake | Drum Brake |
Tyre
| Type Specification | 8.25-16 |
| Front Tyre Pressure | 0.40 Mpa |
| Rear Tyre Pressure | 0.35 Mpa |
