Product Features:
1. The lathe bed was cast steel square tube welding body, strong and without distortion.
2. Heavy-duty structure in "Trapezoid" type, and big Gantry bracket.
3. Double spindles working simultaneously, improve working-efficiency & easily-operating.
4. Advanced DSP Controller system, to engrave/cut 3D designs within multiple-lays.
5. Vacuum absorption table was adding, it can absorp the wooden materials closely.
Guarantee the working-efficiency.
6. Vacuum pump system with six zones, vacuum pump system.
7. Auto-oiling system. Extra time can be saved.
8. High power spindle 4.5KW/5.5KW/6KW/9KW, brushless, water-cooling/air-cooling, working vigorously with low noise.
9. Type3/Artcam/Ucancam/JD Paint/Coreldraw/Castmate/Wentai these related working software.
Technical specification:
Description | Paramater |
TZJD-1325D | |
Working Area (X*Y*Zmm) | 1300mmx2500mmx200mm |
X, Y Structure | Gear Wheel Transmission, Shaft Linear Bearings |
Z Structure | Ball Screw/Gear Wheel |
Table Surface | Bakelite Vacuum Absorption Table |
Max Engraving Speed | 18000mm/min |
Frame | Cast Steel Square tube welding |
Spindle power(KW) | 4.5Kw/5.5kw/6kw/7.5kw/8kw/9kw, *2 |
Max. Power Consumption(Without spindle) | 2.0KW |
Spindle Speed | 6000-18000rpm |
Resolution | 0.005mm |
Repeatability | 0.01mm |
Voltage | AC220V,50/60Hz,1PH(option,380V 3PH) |
Drive motor | Stepper/Servo(option) |
Working Dictate | G Code*.u00*.mmg*.plt |
Operating system | Dsp System |
Interface | USB |
Flash memory | 128M(U Disk) |
Software Compatability | Type3,Ucancam, Artcam Software |
Running Environemt | Temperature: 0℃~45℃ |
Relative humidity: 30%~75% | |
Windows98/2000/xp | |
Machine available | Vacuum absorption table, 5.5KW vacuum pump system, Auto-oiling system, Dust collector with dust cover, Spindle cover device, Rotary device |
Applicable industry:
Wood industry,furniture, woodworker, relief, Advertising industry, breastplate, doorplate, Art-craft industry,
double-color board, bamboo crafts.
Applicable material:
Wood, organic glass, PVC board, KT board, Acryl , MDF board, plastic, metal/aluminum, wood waves,
indoor & our door engraving/carving/cutting, etc.
