8 KW Automatic Hot Melt Glue Wine Bottle, pet bottle Labeling Machine for Yogurt Cup

Delivery Time:7-15days
Certification:CCC, CE, RoHS, UL

8 KW Automatic  Hot Melt Glue Wine Bottle, pet bottle Labeling Machine, Label machine for yogurt cup

Specifications:

Item	Parameters
Model	SSW-4000A
Conveyor belt	2. meters included
Bottle height	According to sample
Paper pipe interior span	According to sample
Main engine speed	12000BPH
Label height	40-200mm
Bottle diameter	40-100mm
Label wide	25-400mm
Label thickness	0.04-0.05mm
Use power supply	AC 3ψ380V
Consumed power	8 KW
Gross Weight	1900Kg
Dimension	4500L*1600W*2000H (mm)

Description:

SSW-4000A automatic hot melt glue labeling machine is specially designed for all kinds of round bottles. Labeling rod takes glue first and label box passes labels to the rod. After rotating, it vacuums labels onto vacuum belt and sticks labels onto bottles.

Applications:

Food and Beverage (Sauces, Spread, Prepared meal, Snacks, Soft drinks, Fruit juices, Water, Alcoholic drinks, etc.) Dairy (Milk-based drink, Yogurt drink, Yogurt Cup, Coffee creamer, Ice cream, etc.) Nutrition product/Supplement (Baby food, Healthy foods, etc.) Home care (Laundry, Fabric care, Detergent, Cleaning products, etc.) Personal Care (Hair care, Soap and Bath products, Oral care, Skin care, Cosmetics, etc.)

Configuration:

Full cover Main engine: Make the operator safety work Type of delivers the bottle: Cylinder Star disc type Separation bottle: Keep the safety space when the bottle enter pastes the sign Enters the sign adjustment group: more accuracy of pastes the sign precision Multicolored control box: Operation human nature Stationary type material-providing shelf: plane type Bottle type or big-and-small different, must change the vacuum drum, Star disc enter the bottle wheel, Separation wheel, Hold-down gear and bottle screw.

Features:

AC 3-Phase inverter and PLC controlled system. Body is built with stainless steel, aluminum alloy and square steel tubes. Structure of square welded tubes and steel beams ensure stable and smooth operations at high speed performance. Centralized lubricating system for simple and effortless on maintenance, lubrication and clean. With photo-sensors to detect label output and automatically self-regulated production speed for integrating production line with other machines. Round plate type suction label, pasting label. Include such mechanisms as label-providing, belt-conveying, label-cutting, wheels-attaching, vacuum-adsorbing, hot sol-conveyance Emergency Stop Safety Device which disables the machine when senses an abnormality. Automated tension control. Automatic label proofread and Cutting System. Automatic warning system and alarm will be activated when it is out of label.

Specification:

PLC: Japan Mitsubishi FX2N-64MT Servo motor: Taiwan Datle Servo drive: Taiwan Datle Encoder:Japan Sanyo Frequency converter: Japan Panasonic Sensor: Japan KEYNECE Fan: Shanghai Touch screen: Taiwan WEINVIEW Cylinder: SMC Melt rubber machine: Nordson
