Features:
TD5T/LY6Y petroleum centrifuge is specially designed for measuring water and deposit in petroleum,in line with GB/T6533-86 standards.It can be used for measuring water and deposit of the crude oil by separation method of centrifuge,as an ideal separation facility of water determination for oil exploitation and research units.
Even and fast heating with high precision control.
Controlled by the microcomputer and driven by the brushless DC motor of variable frequency and high torque,steady speed,reduced motor noise and no need of daily maintenance.
Steel-made structure with protections of hypervelocity and imbalance to ensure the safety of the user and he machine.
Two ways of display including PLC and LED for the user to choose,control parameters such as speed,temperature,and duration can be freely set by the user and changed during the operation to achieve easier application.
Specification:
|
|
TD5T |
LY6Y |
|
Maximum capacity |
4×250ml |
4×8×15ml |
|
Maximum rotate speed |
5000r/min |
5000r/min |
|
Maximum centrifugal force |
4200×g |
4200×g |
|
Rotate speed precision |
±50r/min |
|
|
Motor |
AC Motor |
|
|
Control temperature range |
Control temperature range Room temperature +10℃~70℃ |
Control temperature range Room temperature +10℃~80℃ |
|
Temperature control precision |
±2℃ |
|
|
Time range |
0-99min |
|
|
Noise |
≤65dB |
|
|
Power |
AC220V 50Hz |
|
|
Weight |
50kg |
|
|
Dimension (LxWxH) |
600×540×360mm |
600×490×760mm |
