Steel Cord Conveyor Belt photo-3
Negotiable MOQ: 1 Pole (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Total Employees:
101 - 200 People
Main Markets:
North America, South America, Eastern Europe
Contact Supplier Request Quote Chat Now
CRB Power Rubber Group
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
STEEL CORD CONVEYOR BELT
Belt
strength (ST-NO.)
Max cord diam
(mm)		 Composition
Pitch
(mm)
Standard
working tension
(N/mm)
Thickness t1t2
Standard cover
Thickness t1t2(mm)
Tape reference quality
(kg/m2)
 		 Min.pulley diam
(mm)
Cord strength
KN/piece
ST-630 3 K6×7+IWS 10 90 5×5 19.1 800 6.93
ST-800 3.5 K6×7+IWS 10 110 5×5 20.6 800 8.8
ST-1000 4 K6×7+IWS 12 140 6×6 24.7 800 13.2
ST-1250 4.5 K6×7+IWS 12 175 6×6 25.4 800 16.5
ST-1600 5 K6×19+IWS 12 225 6×6 26 1000 21.12
ST-2000 6 K6×19+IWS 12 285 8×6 30 1000 26.4
ST-2500 7.2 K6×19W+IWS 15 355 8×6 32.2 1250 41.25
ST-3150 8.1 K6×19W+IWS 15 450 8×8 35.7 1400 51.98
ST-3500 8.6 K6×19W+IWS 15 500 8×8 44.9 1500 57.7
ST-4000 8.9 K6×19W+IWS 15 570 8×8 46.6 1600 66
ST-4500 9.7 K6×19W+IWS 16 645 8×8 49 1800 79.2
ST-5000 10.9 K6×19W+IWS 17 715 8.5×8.5 53.6 1800 93.5
ST-5400 11.3 K6×19W+IWS 17 760 9×9 57.5 2000 101
NUMBER OF STEEL CORDS
Belt width(mm) St630 St800 St1000 St1250 St1600 St2000 St2500 St3150 St3500 St4000 St4500 St5000 St5400
800 75 75 63 63 63 63 50 50 50
1000 95 95 79 79 79 79 64 64 64 64 59 55 55
1200 113 113 94 94 94 94 76 76 77 77 71 66 66
1400 133 133 111 111 111 111 89 89 90 90 84 78 78
1600 151 151 126 126 126 126 101 101 104 104 96 90 90
1800   171 143 143 143 143 114 114 117 117 109 102 102
2000     159 159 159 159 128 128 130 130 121 113 113
2200           176 141 141 144 144 134 125 125
2400           193 155 155 157 157 146 137 137
COVER RUBBER PROPERTY AND GRADES
Test item Property indexes
GB9770-2001 DIN22131
D(D) H(H) L(L) P(P) W(W) X(X) Y(Y)

Tensile strength		 Mpa≥ 18 25 20 14 18 25 20
Pull to
break the elongation rate		 %≤ 400 450 400 350 400 450 -400
After aging(70OC.168h) % -25~+25 -25~+25 -25~+25 -25~+25 -25~+25 -25~+25 -25~+25

Change rate of tensile strength

Change rate elongation
Abrasion ≤ 90mm3 120mm3 150mm3 200mm3 90mm3 120mm3 150mm3
ADHHESION STEEL CORD
Strength St630 St800 St1000 St1250 St1600 St2000 St2500 St3150 St3500 St4000 St4500 St5000 St5400
Adhhesion
N/mm GB9770-2001		 60 70 80 95 105 105 130 140 145 150 165 175 180
Adhhesion
N/mm DIN22131-88		 60 70 80 95 105 105 130 140 145 150 165 175 180
