High Speed HD IP IR Led Array Dome Camera, Pan / Tilt Security Cameras

Delivery Time:2 weeks based on sales forecast and 1 month without any sales forecast

High Speed HD IP IR  Led Array Dome Camera, Pan / Tilt Security Cameras

HD IP IR High Speed Dome Camera

01 Product Picture

02 Characteristics

1. Video processor based on TMS320DM368, adopt Linux embedded operation system, low power consumption, stable and reliable.

2. H.264 video encoding format adopted, high compression ratio, better image quality, support dynamic code-rate control.

3. Fully sealed all Aluminum-alloy sealed structure, precise stepper motor, heat-dispersion effective, good water-proof effect, stable performance.

4. Support auto-flip function of the Pan/tilt, automatically adjust movement speed according to lens zoom ratio.

5. Support Preset Position, Left & Right scan, tour etc functions

6. Support 720P/D1/CIF/QCIF, multiple channels code streams can be output simultaneously.

7. Video delay very small, high speed video movement, image crisp and smooth.

8. Network auto-adapt technology, the transmitting frame-rate of the video is automatically adjusted as per the actual bandwidth.

9. Support movement detection, alarm linkage and video mask.

10. Support standard media-transmitting protocol and document format, third party player can play real-time video and recorded files.

11. Support bi-directional audio communication, image snapshot, local or front-terminal recording and playback.

12. Support mobile-phone monitoring, convenient for easy remote monitoring.

13. IR lamps intelligently controlled by the light-sensor, linkage with the IR-CUT, visible distance reaches 150m at night, brightness evenly, image crisp.

03 Technical data

Model	FM-IRHD-135
Camera module	Effective Pixel	1.3 mega pixel
Min. illumination	Color 1.8Lux, B&W 0Lux(IR lamps on)
Iris	Auto/manual
Focus	Auto/manual
Zoom ratio	18x optical
Focal length	f=4.7mm(Wide)～84.6mm(Tel)
View angle	55.2°(Wide) ～3.2°(Tel)
BLC	ON/OFF
Synchronization	External
Scanning mode	2:1 line by line
WB	Auto
AGC	Auto
S/N ratio	>50dB
IR Lamps	IR Light source	IR Led Array
IR Lamps Control	Auto controlled by IR Light Sensor
IR Lamps triggering	Auto/manual
Max. visible distance	100m
Max. power consumption	6W
Pan/tilt	Protocol, Baudrate	Pelco-D, 4800bps (fixed)
Movement speed	Horizontal: 0.5º～120º/S, Vertical: 0.5º～60º/S
Movement range	Pan: 360º endless, Tilt: 0º～90º
Auto-flip	Auto-flip 180 º when vertical 90º
Moving speed auto-control	The moving speed of the Pan/tilt is automatically controlled by the zoom ratio of the camera module
Left &am
