Professional Digital 27.12MHZ High Frequency Welding Machine With PETG for Blister Packing

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Ke-beige		Place of Origin	China
Model Number	KBG-15KWR

Product Description

Delivery Time:7-15 days
Certification:CE

Professional Digital 27.12MHZ High Frequency Welding Machine with PETG for Blister Packing

Application:

Widely using in Blister Packing , toothbrush packing, plastic box making, plastic products welding with APET, PETG, GAG EVA, PP etc. environmental protection materials, also suitable for the products which need to welding / sealing and cutting at the same time ( simultaneously).

High Frequency Welding and Cutting MachineFeatures:

■ Automatic slipway, back-forth or continuous delivering the mould,

accurate orientation, error±20um.

■ Adjustable cutting pressure 1-80 ton, stable and reliable in output, firm in structure.

■ Adopting high sensitive anti-sparkle device to avoid damaging the mould efficiency.

■ Operation mode: non-pneumatic or pure-pneumatic.

High Frequency Welding and Cutting MachineSpecifications:

MODEL	KBG-5000WR	KBG-8KWR	KBG-15KWR	KBG-25KWR
POWER	5000W	8000W	15KW	25KW
POWRR SUPPLY	220V/380V 50/60HZ
FREQUENCY	27.12MHZ	13.56MHZ
INPUT POWER	8KVA	15KVA	25KVA	35KVA
RECTIFIER	SILICON DIODE
VACUUM TUBE	7T85RB	7T69RB	8T85RB	8T25RB
MAXPRESSURE	5T/10T	10T/15T	20T	30T
MAX GAP OF ELECTRODES	200MM
SIZE OF ACTIVE HORN	150MM
SIZE OF UP ELECTRODE	300*400	350*500	600*800	700*800
SIZE OF DOWN ELECTRODE	400*500	450*600	700*900	800*900
RANGEOF TEMPERATURE	30~200℃ Adjustable
WELDING TIME	0~10S Adjustable
PRODUCTIVITY	≦5000times/8h
NET WELGHT	1T	1.5T	2.5T	3T
DIMENSION	1920Х1200Х2060	1920Х1200Х12060	2650Х2550Х2240	2850Х2550Х2440
