Help CenterPtfe Filling Pipes/tubes
Related Products
Specifications
insulted pipe casing for wire ,pipe for corrssive fluids,electric insulated parts used in high frequent conditions.
1,Features:
There are three types of PTFE pipes:
For a pipe with outside diameter1~25mm and thickness of wall 0.1~2.5mm,we chose imported polymized PTFE resin and process it by pressing;For a pipe with outside outside diameter25~200mm and thickness of wall 1.5~8mm,we choose suspended PTFE resin and process it by extruding ;For a pipe with outside diameter 25~1200mm and thickness of wall 5~500mm, we process it by die pressing .
2,Specifications:
TYPES |
Specifications |
||
Outside diameter(mm) |
Wall thickness(mm) |
Length(mm) |
|
Pressed pipe |
1 ~ 25 |
0.1 ~ 2.5 |
Produced under requirements |
Extruded pipe |
25 ~ 200 |
1.5 ~ 8 |
Produced under requirements |
Die pressed pipe |
25 ~ 1200 |
5 ~ 500 |
100 ~ 300 |
3,Main properties:
Properties |
Unit |
Result |
Apparent density |
g/cm³ |
2.10~2.30 |
Tensile strength(min) |
Mpa |
18 |
Crack elongation(min) |
% |
230 |
