Ignition Controller
- 200 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
Product Details
Brand Name: | Kisawa | Place of Origin: | China | Model Number: | IFT458 |
Product Description
Control the burner ignition and flame monitoring;
Power supply: 220V
Power: 18VA+25VA
IFT458 controller (internal transformer)
IFT458 is applied to start ignition directly, burner monitor, control burner with combustion air or atmospheric burner(single valve control) and other systems without flush or flush controlled by other controllers.
1.Control ignition of burner for any power
2.Ionizing or UV monitoring
3.Ignition and monitor may share an electrode
4.Lock and alarm if the flame goes out.
5.Terminal of fire wire and zero wire cannot be exchanged
6.Two sets output terminals for normal and fault
7.Tested and certificated according to EC Directive90/396/EEC and European gas application standard EN298
8.It will be best that spark plug wire is shorter than 1m.
10.Reset only when alarm lamp is on.
11.Degree of protection: IP40, according to IEC529
12.Fuse: 3.15A, slow-melted H type according to IEC127-2/5
13.Environment temperature: -20°C - +60°C, without condensing
14.Current output: maximum 2A for each, 2.5A in total
