1BZ hydraulic trailed off set heavy duty disc harrow for tractor
1.About our company
[1Our company is Shandong Yucheng Ali Disc Harrow co,ltd,speciallizing in deveoping,selling and producing agricultural machinery.such as disc harrow,disc plough,share plough,rotary tiller,potato planter,box blade,ridger and so on.
[2] Our company has passed ISO9001:2000 quality management system certification.
[3] Our company located in Shandongyucheng high and new technology,Our products are exported to Amecica,France,Germany,Russia,Nigeria and so on .
2.About 1BZ hydraulic trailed off set heavy duty disc harrow for tractor
This series of 1BZ hydraulic trailed offset heavyduty disc harrow is mainly applicable to clean the crop residue before tillage, break the hardened and impervious soil surface, crush and spread straw into the field, shatter soil after tillage, and level the land and preserve soil moisture. It can be used as tillage machine instead of plough on the cultivated land. With the efficient productivity, reasonable utilization of the power, great ability of cutting and shattering the soil , the soil surface is smooth and loosening after harrowing, it is well suitable for heavy clay soil, waste land and weedy field as well.
Having absorbed all advantages from such machines of foreigners and Chinese, it is designed according to the standarded assembled structure, the main frame is welded with rectangular tubes, on which assembled with hydraulic lifting transportation wheels, adjustable spring device and special used bearing assemblies.Therefore this machine is strong and durable for operation and easy to be adjusted and maintained with the reasonable structure, small turning radius ,and is convenient for transportation , etc.
|
Model |
unit |
1BZ-1.8 |
1BZ-2.2 |
1BZ-2.5 |
1BZ-3.0 |
1BZ-3.4 |
1BZ-4.0 |
|
Working width |
m |
1.8 |
2.2 |
2.5 |
3.0 |
3.4 |
4.0 |
|
Working depth |
mm |
180~200 |
180~200 |
180~200 |
180~200 |
180~200 |
180~200 |
|
Q’ty of disc |
|
16 |
20 |
24 |
28 |
32 |
36 |
|
Disc diameter |
mm |
660(650) 600(610) |
660(650) 600(610) |
660(650) 600(610) |
660(650) 600(610) |
660(650) 600(610) |
660(650) 600(610) |
|
total weight |
kg |
1100 |
1250 |
1350 |
1450 |
1550 |
1700 |
|
Matched power |
hp |
≥70 |
≥80 |
80~100 |
100~120 |
120~150 |
140~160 |
|
Linkage |
(Trailed ) |
