Help CenterWhite PTFE Film
US$ 10 - 18
MOQ: 100 Kilograms
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
senrong
Model Number:
srrgh0017
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Shandong, China
Brand Name
senrong
Model Number
srrgh0017
1,Characteristics:
Two kinds: Directional and non directional ptfe film, smooth and level surface, dimensional accuracy.
2,Application:
Capacitor dielectric and wrie insulation, electrical instrument insulation and so on.
3,Specifications:
| Item | Thickness | Thickness allowance | Width | Length(cm) |
| Directional | 0.015-0.040 | ±10% | 30-120 | ≥100cm |
| Half-directional | 0.030-0.10 | ±10% | 60-120 | ≥100cm |
| Non-directive | 0.02.-0.10 | ±10% | 60-300 | ≥100cm |
4.Main properties:high-density:tensile strength≥30Mpa,elongation at rupture≥30%,Dc breakdown coltage(normal
temperature):200KV/M average, the lowest value 40KV/M semi-density:tensile strength≥20Mpa,elongation at rupture≥60%,Dc breakdown coltage(normal temperature):60KV/M average, the lowest value 6KV/M common:tensile strength≥10Mpa,elongation at rupture≥100%,Dc breakdown coltage(normal temperature):30KV/M average.
