Launch X431 TOP $4,589 Free Shipping via DHL
US$ 4589 - 4589
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Uobd2s.com
Place of Origin:
China
Model Number:
Launch X431 Top
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Launch X431 Diagun Printer $299 Free Shipping via DHLUS$ 299 - 299MOQ: 1 Piece -
Launch X431 Diagun Update via Email $890.00 Free Shipping Via DHLUS$ 890 - 890MOQ: 1 Piece
-
BMW GT1 DIS V57 SSS V42 $499.00 Free Shipping Via DHLUS$ 499 - 499MOQ: 1 Piece
-
T4 Mobile Plus Original for Land Rover $3,230 Free Shipping via DHLUS$ 3230 - 3230MOQ: 1 Set
-
Renault CAN Clip V119 $299.00 Free Shipping Via DHLUS$ 299 - 299MOQ: 1 Piece
Brand Name
Uobd2s.com
Place of Origin
China
Model Number
Launch X431 Top
info@uobd2s.com or-marian@hotmail.com
Launch X431 TOP $4,589 Free shipping via DHL
Product description
X-431 TOP Automotive Diagnostic Workstation is an upgrade on X-431 diagnostic scanner. Working on Bluetooth wireless communications, it has expanded functions to cover oscilloscope, engine analyzer, sensor signal simulator and includes an automotive database.
1.Vehicle diagnosis :
1)Wireless diagnosis function for the diagnosis of electronic control systems of most models in the word;
2)Updates at the same pace with x-431 .
2.Engine ignition analysis:
1)Display engine primary and secondary ignition waveform with single-cylinder, raster, parade, bar pattern and etc.;
2)Unique multi-cylinders synchronization simulation technology to enable more efficient and convenient testing.
3.Vehicle service database:
1)Equipped with detailed information including electronic system and circuit diagram;
2)Accurate location of electronic components and details of the connection principle;
3)Vivid display of color graphics on screen.
4.Vehicle oscilloscope:
1)Adopt maximal sampling frequency of 20MHz
2)Test for output waveform of various sensor/actuator available;
3)Analysis fault of seonsor/actuator
5.Sensor simulation and test:
1)Simulaiton of DC voltage signal, inpulse signal, sensor standard waveform signal and hand-drawn waveform available;
2)Simulation of sensor standard waveform for the confirmation of sensor troubles.
Product character
Apart from keeping and enhancing all the functions of the X-431, X-431 TOP enables tests of vehicles at a distance of 15 meters with the help of Bluetooth communication technology. X-431 TOP can give you the most efficient, stable and easy information without leaving your desk.
Equipped with the most comprehensive functionality, it can save the expense for the users to buy, store, upgrade single function products and conduct training. X-431 TOP provides a large technical database for automotive service, including 1. Tips on DTC-based vehicle service, 2. Standard data stream value, 3. Component wiring diagram, 4. Standard waveforms for ignition.
Product parameter
Vehicle oscilloscope function:
Channel: 4 CH
Frequency: 20MHz
Measuring voltage: -150 V ~ +150 V
Sensor simulation function:
DC voltage signal:
1.Output range: -12~+12 V
2.The maximal output current: 40 mA
3.Output precision: ±5 %
Squarl-wave signal:
1. Impulse frequency: 0.1~15 kHz
2. Range: -12~+12 V
3. Duty ratio: 10~90 %
4.Output precision: ±5 %
Sensor standard signal:
1. Frequency range: 0.1~100 Hz
2. Range: -12~+12 V
3.Output precision: ±5 %
Hand-draw waveform Signal:
1. Frequency range: 0.1~100Hz
2. Range: -12V~+12V
3.Output precision: ±5 %
Sensor test module:
Voltage test: 1.Measuring range: DC -400~+400 V
2.Input impedance: 10 M?.
3.Check precision: ±5 %
Resistance test:
1.Measuring range: 0~1 M?
2.Check precision: ±5 %
Frequency test:
1.Measuring range: 1~15 kHz
2..Input impedance: 300 k?
3.Input range: 1~12 V
4.Check precision: ±1 %
