High speed Films(non-sticky) Labels Slitting and rewinding machines AC 220V 50Hz / 1000W

Delivery Time:In 10 working days
Certification:ISO9001:2008

High speed Films(non-sticky) Labels Slitting and rewinding machines AC 220V 50Hz / 1000W

Technical Parameter

Model:VPA-805

Max.linear speed:100m/min

Speed adjustment:frequency conversion

Max. Unwinding Diameter:350mm

Max. Winding Diameter:350mm

Unwinding Width:50-400mm

Max.Slitting Width:350mm

Min.Slitting Width:8mm

pattern of winding and unwinding:winding shaft tension adjusting by the Magnetic powder clutch,

unwinding shaft by brake belt；

Material fixtures:Inflatable shaft bulging

Material:Films(non-sticky)Labels

Material Core:3 inches

Slitting device:Vertical sword,10 sets small sword

Rectification function:Can automatic correction when unwinding

Power:AC220V 50Hz/1000W

dimension:L900mm X W520mm X H1280mm

Weight:150Kg

Description:
Width slit-setting freely
Speed adjusting by inverter , operating steadily
Stop automatic when reach the presetting length
Operation panel intuitive and convenient
Practical operating table
Slitting sword can be adjusted flexibly

Applications:
Used for films and labels slitting＆rewinding.
Wide application, strong practical applicability,especially suitable for labels industries.

Competitive Advantage:
We are manufacturers, so we can provide high-quality and low-cost products
Wide application, strong practical applicability,especially suitable for labels industries.
