12000 Dyneema Rope Winch With Keyway Cam

12000 Dyneema Rope Winch With Keyway Cam thumbnail-1
12000 Dyneema Rope Winch With Keyway Cam thumbnail-2
12000 Dyneema Rope Winch With Keyway Cam photo-1
12000 Dyneema Rope Winch With Keyway Cam photo-2
Negotiable MOQ: 20 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
hc winch
Place of Origin:
China
Model Number:
SC12.0WX
Contact Supplier Request Quote Chat Now
Ningbo Haochuang Precision Machinery Co., Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name hc winch
Place of Origin China
Model Number SC12.0WX

Waterproof high quality winch with cold extrusion 20Cr steel gears to meet toughest pulling demands, one 500A solenoid, 100% function and pulling test



SC12.0WX  12V or 24V

12000LB Heavy Duty Electric Winch

Specification:

Rated line pull: 12000lb (5443kg) single line

Motor: 6.0hp/4.5kw, series wound 12V

Control: Remote switch, 12ft (3.7m) lead

Gear train: 3 stage planetary

Gear reduction ratio: 191:1

Clutch: key way cam

Braking: Automatic load-holding brake

Drum size: Ø2.5″*L8.8″ (Ø63.5mm*L224mm)

Dynema rope: Ø10.0mm*28m

Fairlead: Polished and Anodized aluminum fairlead

Wireless Remote control: Optional

Battery recommended: 650 CCA minimum for winching

Battery leads: 2 gauge, 72" (1.83m)

Finishing: Black, dark grey coating

Overall dimension (L*W*H): 538*160*214mm

Mounting bolt pattern: 10″*4.5″ (254*114.3mm)

N. W. /G. W.: 27/29KG

Key way cam clutch Features

1. Gears are 20Cr steel crafted with cold extrusion and heat treatment, to meet toughest pulling demand.

2. Gear ratio 191:1, high line speed.

3. Rotating to get your winch fully engaged and disengaged both in two directions.

Winch features

1. Series wound high hp motor, delivers plenty of power.

2. Gears are made of 20Cr steel, crafted with cold extrusion and heat treatment, to meet your toughest pulling demand.

3. Key way cam clutch 191:1, rotating to get winch fully engaged and disengaged; or sliding ring gear

4. 500A solenoid, compact design and sealed. Durable winching.

5. sealed winch and solenoid

6. Fine precision processed transmission shaft, to reduce vibration and noises.

7. We have 100% testing on winch pulling capacity and function.

8. Safe packages-foam and honeycomb carton / pallet
