Brand Name:
GHE
Place of Origin:
China
Model Number:
GHE360-Z-A
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
16 Tons Knuckle Boom Truck Mounted Crane for ContainerUS$ 1 - 1MOQ: 1 Unit -
Truck Mounted Crane--knuckle Boom Type With Multi-peel GrabUS$ 6000 - 6000MOQ: 1 Unit
-
Telescoping Boom Truck Mounted CraneUS$ 5000 - 5000MOQ: 1 Set
-
20 Feet Container Spreader &Container Hanger Frame (GHE-CS-300-A)US$ 123 - 123MOQ: 1 Set
-
Hot Sell Electro Hydraulic Orange Peel GrabUS$ 1 - 1MOQ: 1 Set
Brand Name
GHE
Place of Origin
China
Model Number
GHE360-Z-A
We adopt German technology and most of our R&D specialists are from Germany, and constantly self-development and introduction of foreign advanced technology, leading the direction of the domestic truck mounted crane's development.
Sales and after sales service network covers the whole of the country, and expand overseas.
Superior product performance, safe and reliable.
Simple operation, operating speed, economical and practical.
| character of productor | |||||
|
1. All hydraulic valve, sealings are origin import from USA or EUR, Make sure crane long durability safety and reliability; |
|||||
|
2. Steel structure adopt high strength steel welding, boom use type of hexagon section, to make crane light dead weight with high strength. |
|||||
| 3. All structure welding by carbon dioxide are welding, make perheating processing before and X ray detection after, Then sand blasting treament. | |||||
| Model | GHE360 | unit | |||
| Max Lifting moment | 36 | t. m | |||
| Max Lifting capacity | 18000 | Kg | |||
| recommend power needed at recommend oil flow | 30 | kw | |||
| Max oil flow of hydraulic system | 60 | L/min | |||
| Rated pressure of hydraulic system | 285 | Bar | |||
| Oil tank volume | 160 | L | |||
| Rotation angle | 385° | Degree | |||
| Dead weight | 4600 | Kg | |||
| Installation space | 1400 | mm | |||
| Working radius(m) | 1.85 | 3 | 4.4 | 6.4 | 8.5 |
| Lifting capacity(Kg) | 18000 | 11500 | 7500 | 5000 | 4000 |
| Working radius(m) | 10 | 12.44 | |||
| Lifting capacity(Kg) | 3200 | 2500 |
| character of productor | |||||
|
1. All hydraulic valve, sealings are origin import from USA or EUR, Make sure crane long durability safety and reliability; |
|||||
|
2. Steel structure adopt high strength steel welding, boom use type of hexagon section, to make crane light dead weight with high strength. |
|||||
| 3. All structure welding by carbon dioxide are welding, make perheating processing before and X ray detection after, Then sand blasting treament. | |||||
| Model | GHE360 | unit | |||
| Max Lifting moment | 36 | t. m | |||
| Max Lifting capacity | 18000 | Kg | |||
| recommend power needed at recommend oil flow | 30 | kw | |||
| Max oil flow of hydraulic system | 60 | L/min | |||
| Rated pressure of hydraulic system | 285 | Bar | |||
| Oil tank volume | 160 | L | |||
| Rotation angle | 385° | Degree | |||
| Dead weight | 4600 | Kg | |||
| Installation space | 1400 | mm | |||
| Working radius(m) | 1.85 | 3 | 4.4 | 6.4 | 8.5 |
| Lifting capacity(Kg) | 18000 | 11500 | 7500 | 5000 | 4000 |
| Working radius(m) | 10 | 12.44 | |||
| Lifting capacity(Kg) | 3200 | 2500 |
| character of productor | |||||
|
1. All hydraulic valve, sealings are origin import from USA or EUR, Make sure crane long durability safety and reliability; |
|||||
|
2. Steel structure adopt high strength steel welding, boom use type of hexagon section, to make crane light dead weight with high strength. |
|||||
| 3. All structure welding by carbon dioxide are welding, make perheating processing before and X ray detection after, Then sand blasting treament. | |||||
| Model | GHE360 | unit | |||
| Max Lifting moment | 36 | t. m | |||
| Max Lifting capacity | 18000 | Kg | |||
| recommend power needed at recommend oil flow | 30 | kw | |||
| Max oil flow of hydraulic system | 60 | L/min | |||
| Rated pressure of hydraulic system | 285 | Bar | |||
| Oil tank volume | 160 | L | |||
| Rotation angle | 385° | Degree | |||
| Dead weight | 4600 | Kg | |||
| Installation space | 1400 | mm | |||
| Working radius(m) | 1.85 | 3 | 4.4 | 6.4 | 8.5 |
| Lifting capacity(Kg) | 18000 | 11500 | 7500 | 5000 | 4000 |
| Working radius(m) | 10 | 12.44 | |||
| Lifting capacity(Kg) | 3200 | 2500 |
