Wire rope pulling hoist (Aluminium material)
Wire rope pulling hoist also named wire rope pulling winches,wire rope pulling machines,manual wire rope pulling tools and so on.
Wire rope pulling hoist have three kinds of capacity:800kg,1600kg.3200. Normally it has 20 meters wire rope.
Finer wire rope pulling machines is Aluminium material which means long working life.
Wire rope pulling winches is an extremely tools for pulling,lifting and securing goods.which is easy and safe to operate.
Via wire rope pulling hoist is easy to move objects several tons in weight by one person.
This winches has lower maintenance requirements,to save your cost.
800 KG wire rope pulling hoist specifications:
Model: FR-080
Rated Capacity(KG): 800 kg
Rated Capacity(LBS): 1762 LBS
Rope Advance Per Full Stroke:55mm
Wire Rope DIA (Ø in mm) :8.3 mm
Wire Rope Safety Factor:5.0 times
Static Load Safety Factor:4.0times
Max.Dynamic Load:1250kg
N.W without Rope:6.0kg
Wire Rope Standard Length:20 meters.
Package Size:428*64*325mm
1600 KG wire rope pulling hoist specifications:
Model: FR-1600
Rated Capacity(KG): 1600 kg
Rated Capacity(LBS): 3524 LBS
Rope Advance Per Full Stroke:55mm
Wire Rope DIA (Ø in mm) :11.0 mm
Wire Rope Safety Factor:5.0 times
Static Load Safety Factor:4.0times
Max.Dynamic Load:2000kg
N.W without Rope:11.0kg
Wire Rope Standard Length:20 meters.
Package Size:545*97*286mm
3200 KG wire rope pulling hoist specifications:
Model: FR-3200
Rated Capacity(KG): 3200 kg
Rated Capacity(LBS): 7050LBS
Rope Advance Per Full Stroke:40mm
Wire Rope DIA (Ø in mm) :16.0mm
Wire Rope Safety Factor:5.0 times
Static Load Safety Factor:4.0times
Max.Dynamic Load:4000kg
N.W without Rope:22.0kg
Wire Rope Standard Length:20 meters.
Package Size:660*116*350mm
