GFS-8 Energy saving high-speed Precision Grinding Machine for chemical industry
Description:
■ This machine is high speed operative grinder. Being adopted the knives where one side knife-edge
is sharp and the other is re-impact, the raw material can be crushed through cutting of high speed rotating knives.
Different knives can be choose in accordance with different raw materials. Different size can be got through
exchanging different sieve.
Application
■ This machine adopts the principle of mixing and spraying powder to design and manufacture. It has
wide application and is wide used for pharmaceutical industry, foodstuff industry, chemical industry and so on.
■ The structure of machine is simple. The assembling and disassembling and clean of machine are
very convenient. All parts that will contact with raw materials inside the chamber are made of stainless steel.
So it withstand acidic corrosion. The quality of crushed raw material is in conformity with the requirement
of health. This machine has many advantages such as the movement of machine is very convenient and
its operation is smooth and its noise id low and its crushed effect is god and its consumption is low.
TECHNICAL PARAMETERS
|
Model |
GFS-8 |
GFS-16 |
GFS-28 |
|
Power of motor(kw) |
3 |
7.5 |
11 |
|
Productive capacity (kg/h) |
10-100 |
50-300 |
100-500 |
|
Revolution (rpm) |
4000 |
4000 |
4000 |
|
degree of finished product (content≤85%) |
12-120mesh |
12-120mesh |
12-120mesh |
|
Overall dimension of model A(LxWxH) |
800x550x1250 |
900x660x1350 |
1000x750x1665 |
|
Weight(kg) |
150 |
250 |
350 |
Remark:
the parameters in table will be different because of raw materials and requested mesh, for reference only.
