Sealing Oil Band System Used on Vessel Pipe

AC Flexible grease fiber corrosion prevention seal tape Product performance parameter Item Product performance Color Yellow brown Composition Corrosion prevention seal tape immerged with painted at tow faces with synthetic fiber by flexible inert grease, filler, corrosion inhibitor and preservative Function Stable composition with good flexibility and plastic and good insulation able to be against corrosion from inorganic acid, alkali and salt, and a layer of oily protection layer on the work piece to separate water and air without hardness, solidification cracking , applicable in overlapped Insulation voltage ≥16KV, 55%, overlapped. Weight Average ≥1.45kg/square meter Thickness°C Average ≥1.20mm Solution resistant to 10% hydrochloric acid (immerged for 7 days) No abnormal change Solution resistant to 10% potassium chloride (immerged for 7 days) No abnormal change No abnormal change Operation temp -5°C to 55°C Applicable temp Normal temp.:-50°C to 75°C, high temp. -50°C to 110°C Length 10m/coil as per requirement Width 50,100,150,200,300 50, 100,150,200,300mm or other width Package Plastic package in paper case for case for each coil of tape,18square meters in a case AC external band Product performance parameter Material Special self-adhesive PVC sealing tape Color Black or yellow Thickness ≥0.10 Breakage extension rate (%) ≥100 Function Good flexibility to adhere at overlapping and wound at exterior of oily band corrosion prevention layer tightly against loss of grease to improve mechanical protection intensity and electric insulation Package 41m /coil width 50,100and 150mm in paper case AC Flexible grease fiber corrosion prevention seal Product performance parameter Item Product performance Color Yellow-brown Composition Semi-condensed paste composed with inertia grease, filler Function Corrosion inhibitor and preservatives to form oily membrane to improve work piece surface with compatibility with sealing band and putty Solid content ≥55°C Operation temp -5°C to 55°C Applicable temp Normal temperature -50 to 75°C, high temperature -50°C to 110°C Painting amount 2-5 square meter/kg Package 3kg or 5kge per can In paper box AC Flexible grease fiber corrosion prevention sealing putty (mortar) Product performance parameter Item Product performance Color Grease or brown Composition Flexible mortar mixer is composed with inertia grease, filler, corrosion inhibitor, preservatives, reinforced short fiber(or PET form) Feature Such putty is provided with good flexibility and plasticity and plasticity and good insulation and resistance to inorganic acid, asphalt and slat stable composition without hardening and solidifications. Function To be used at cavity of valve, flange to improve irregularity of parks for smooth winding oily band with good sealing. Surface density ≥0.85 gram/cubic meter Operation temp -5°C to 55°C Applicable temp Normal temperature -50 to 75°C, high temperature -50°C to 110°C Package 3kg/pc with plastic package In paper box, 8pcs/box.24kg/box,or other package Marine Anti-corrosive Petrolatum Tape Marine Anti-corrosive Petrolatum Tape is specially designed for use on vessel. It is a neutral petrolatum based system designed to isolate all metal surface. It is developed for long-life protection against corrosion and the water-proofing of pipes, flanges and valves for marine use and the most severe atmospheric, buried and submerged metal surfaces. Anticorrosive Tape has a high degree of conformability which allows for application over irregular surface profiles in ships. It is non-toxic and no V.O.C. The tape offers stability in composition and plasticity over a wide temperature range, Non- hardening and non-cracking, highly resistant to acids, alkalis and salts, unaffected by vibration. It can be used very simply. The system includes tape, paste, mastic. outer protective tape. Petrolatum Tape Specifications: Thickness: 1.2 mm average Weight: 1.2-1.4 kg/M² Elongation: 20% Temperature: 5-55 ºC The following is the code of Petrolatum tapes: Tape Width IMPA CODE ISSA CODE Rolls/Box 50mm 81.24.71 75.550.01 36 100mm 81.24.72 75.550.02 18 150mm 81.24.73 75.550.03 12 200mm 81.24.74 75.550.04 8 300mm 81.24.75 75.550.05 6 Petrolatum Paste : A primer for increasing the adhesion of Anticorrosive Tape Paste 81.24.81 75.551.01 Petrolatum Mastic:Filler on the uneven surfaces. Mastic 81.24.83 75.551.02 Marine Anti-corrosive Petrolatum Tape Marine Anti-corrosive Petrolatum Tape is specially designed for use on vessel. It is a neutral petrolatum based system designed to isolate all metal surface. It is developed for long-life protection against corrosion and the water-proofing of pipes, flanges and valves for marine use and the most severe atmospheric, buried and submerged metal surfaces. Anticorrosive Tape has a high degree of conformability which allows for application over irregular surface profiles in ships. It is non-toxic and no V.O.C. The tape offers stability in composition and plasticity over a wide temperature range, Non- hardening and non-cracking, highly resistant to acids, alkalis and salts, unaffected by vibration. It can be used very simply. The system includes tape, paste, mastic. outer protective tape. Petrolatum Tape Specifications: Thickness: 1.2 mm average Weight: 1.2-1.4 kg/M² Elongation: 20% Temperature: 5-55 ºC The following is the code of Petrolatum tapes: Tape Width IMPA CODE ISSA CODE Rolls/Box 50mm 81.24.71 75.550.01 36 100mm 81.24.72 75.550.02 18 150mm 81.24.73 75.550.03 12 200mm 81.24.74 75.550.04 8 300mm 81.24.75 75.550.05 6 Petrolatum Paste : A primer for increasing the adhesion of Anticorrosive Tape Paste 81.24.81 75.551.01 Petrolatum Mastic:Filler on the uneven surfaces. Mastic 81.24.83 75.551.02
