Hot Melt technology PN 1.25 Mpa HDPE High Density Polyethylene Pressure Pipe

Certification:CE, ISO9001,ISO14001,GB/T28001,Jiangsu Famous Stand

Hot Melt technology PN 1.25 Mpa HDPE High Density Polyethylene Pressure Pipe

Overview:
PE pipe for water supply of Jiangte, imported PE100 class quality materials, imported equipment, in accordance with GB/13663-2000 standard production, good solderability, resistance to evironmental stress cracking resistance and resistance to rapid crack resistance, widely used in municipal   water supply and drainage, rural water reform, telecommunications, petrochemicals, agriculture, irrigation and other areas.

Features:
Corrosion resistance, long service life: High-density polyethylene (PE) has excellent chemical stability For good mechanical properties, corrosion resistance, high strength, , can be used for more than 50 years in normal use conditions;
Health, environmental protection: No scaling, no breeding of bacteria, solving the secondary pollution of drinking water . Good flexibility: the high impact strength, resistance to earthquake resistance, distortion;
Light weight, transport, easy to install, easy to transport, install: a small amount of construction works if use high-density polyethylene (PE) pipe, construction of low cost, construction with speed, integrated low-cost;
Flow resistance: smooth wall, low friction, fluid resistance and lower pressure loss and water piping in energy consumption, significant in economic advantages;
Piping connections convenient and reliable: high density polyethylene (PE) pipe connection, make the melt method adopts integration, leak-off pipe, safe and reliable.

HDPE Pipe Price Sheet of Jiangsu Jiangte Technology  Co., Ltd
Product	Pressure Level	PN 1.6 Mpa	PN 1.25 Mpa	PN 1.0 Mpa	PN 0.8 Mpa	PN 0.6 Mpa
Dia	Dia*thickness	Dia*thickness	Dia*thickness	Dia*thickness	Dia*thickness
	20	20×2.3*	20×2.0*
25	25×2.3*	25×2.1*
32	32×3.0	32×2.3*
40	40×3.7	40×2.9*	40×2.3*
50	50×4.6	50×3.7*	50×2.9*
63	63×5.8	63×4.7	63×3.7*
75	75×6.8	75×5.6	75×4.5
90	90×8.2	90×6.7	90×5.4	90×4.3
110	110×10.0	110×5.1	110×6.6	110×5.3	110×4.2
125	125×11.4	125×9.2	125×7.4	125×6.0	125×4.8
140
