Home > Apparel & Accessories > Functional Shoes > Work & Safety Shoes > DZ101H-VIP 800W High Power VIP Jammer,vehicle-mounted VVIP Jammer
DZ101H-VIP 800W High Power VIP Jammer,vehicle-mounted VVIP Jammer
Negotiable
MOQ: 1 Pair (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Dezhen
Place of Origin:
China
Model Number:
DZ101H-VIP
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
1500W 20-6500MHz Vehicle-mounted Anti-bomb Jammer,wire Control Penal,block Frequency AdjustableNegotiableMOQ: 1 Piece -
DZ101L 20-3000MHz 530W High Power Man-pack VVIP Jammer, Digital Portable JammerNegotiableMOQ: 1 Piece
-
4 Band 10W Wifi Cellular Signal Jammer Blocker Isolator Shield Wifi GSM DCS 3G, With Remote Control,cover 50 MetersNegotiableMOQ: 1 Piece
-
Power Adjustable Wifi GSM 3G Jammer Blocker Shield,apply for Wifi/900/1800/1900/3G Mobile,block Range AdjustableNegotiableMOQ: 100 Pieces
-
5 Antennas High Power Wifi/ Bluetooth GSM 3G Mobile Signal Jammer Blocker Isolator Shield,with IR Remote,cover 50mNegotiableMOQ: 100 Pieces
Brand Name
Dezhen
Place of Origin
China
Model Number
DZ101H-VIP
The DZ101H-VIP is a vehicle mounted high power jammer designed for blocking remote controlled improvised explosive devices used by terrorist.
The DZ101H-VIP is using state-of-art technology for maximum performance and jamming the signals transmits to activate bombs.
Jamming radius of DZ101H depends on several conditions such as transmitter frequency and output power, distance to receiver, and obstacles between, etc.
The system use Broadband Omni-Directional antennas for 360 degreee protection.
Because of the variety of jamming targets and a wide range of uncertainties, we have adopted the more advanced and effective jamming signal modulation method, which will increase the jamming efficiency in each band, so that to provide security protection and ensure the safety of VVIPs.
Techinical Features
1.TX-Frequency:from 20Mhz to 3000MHz.
2.Antenna:10pcs 360. Omni directional antennas.
3.Output power adjusting per Band and Bandwidth adjusting within Band by LCD.
4.Output power on/off per band.
RF Characteristics
1. Output Power: 800 Watts
2. Range jamming(Radius): 35m to 500m (depend on site signal strength and environment condition.)
3. Internal Modulation: Direct Digital Synthesis
4. Power Supply: 220V AC/ 27V DC(optional, by inverter)
5. Sweep rate: Fixed
6. Remote Control: ON/OFF per band
7. Antenna: External Omni-Directional Antenna
8. Power Amplifier Protectors: Over Heat-Thermal protector
9. Each module can adjust power, warning standing wave indicator and warning temperature indicator separately.
Jamming Frequency Range
Frequency Band: 20-3000 MHz, Full band jamming-No Gaps
Physical Data
Dimensions:56x48.5x64.5cm
Weight: 50KG(With Power Supplier,Not including betteries)
Environment of operation
Operating Temp: -40 to +65 Celsius Degree
Humidity: 5% - 80%
Optional Accessories
Backup Battery: Yes
If batteries needed,please inform us your requirement of working hours.
Power Division
Frequency Band Output power
1. 20-80MHZ 50 W
2. 80-200MHZ 50 W
3. 200-500MHZ 200 W
4. 500-975MHZ 100 W
5. 975-1450MHZ 50 W
6. 1450-1925MHZ 50 W
7. 1925-2400MHZ 50 W
8. 2400-2500MHZ 50 W
9. 2500-3000MHZ 50 W
14. 930-960MHZ 50 W
15. 1800-1990MHZ 50 W
16. 2110-3000MHZ 50 W
Total 800 W
**Remark :TX Frequency and Each band output power is optional according to your requirments.
Spare Parts:
1. 1 pcs Backup Battery(Optional):
2. 16 Omni Directional Antennas;
3. 16 pieces Cables with length 07 meters Extend to Install Antennas;
Application area
Mainly used in the area of big prison,big ground,battalion as well as illegal congregation,illegal demonstration,military rehearse,special action etc.
Order and Shipping information:
Price terms:EXW price not including custom tax fee,bank transfer fee,buyers are response for it.
Package items:One MOBILE SIGNAL JAMMER kit DZ101H-VIP,15 pieces omni antennas,one power supply,installation screws,one user mannual.
Payment Terms: Paypal,T/T,L/T,Western Union.
Delivery date:Usually 20 working day after receive your deposit.
Min. Order:One charged sample to test quality.
Transportation: DHL,FFEDEX,EMS or According to your special request.
Trademark: Dezhen
Port:Shenzhen China
Import Note:
1.Please contact us whether goods available or not before your order.
2.Please inform us the specifications of the power supply plug you need.
3.We fix the frequency according to your country mobile frequency.If you need special frequency,please inform us.
Warranty & Maintenance:
1.We do our best to serve our each customer the best that we can.
2.We will refund you for items returned within one month with no damage that affects second selling after we send out the goods. A full refund will be given if items are returned in their original condition.Merchandise which is damaged or missing components is not refundable.
3.Three month to replace if quality problem.
4.12 months maintenance warranties.
5.Lifelong technical support.
6.Buyers are responsible for return shipping with proper packaging for warranty items
The DZ101H-VIP is using state-of-art technology for maximum performance and jamming the signals transmits to activate bombs.
Jamming radius of DZ101H depends on several conditions such as transmitter frequency and output power, distance to receiver, and obstacles between, etc.
The system use Broadband Omni-Directional antennas for 360 degreee protection.
Because of the variety of jamming targets and a wide range of uncertainties, we have adopted the more advanced and effective jamming signal modulation method, which will increase the jamming efficiency in each band, so that to provide security protection and ensure the safety of VVIPs.
Techinical Features
1.TX-Frequency:from 20Mhz to 3000MHz.
2.Antenna:10pcs 360. Omni directional antennas.
3.Output power adjusting per Band and Bandwidth adjusting within Band by LCD.
4.Output power on/off per band.
RF Characteristics
1. Output Power: 800 Watts
2. Range jamming(Radius): 35m to 500m (depend on site signal strength and environment condition.)
3. Internal Modulation: Direct Digital Synthesis
4. Power Supply: 220V AC/ 27V DC(optional, by inverter)
5. Sweep rate: Fixed
6. Remote Control: ON/OFF per band
7. Antenna: External Omni-Directional Antenna
8. Power Amplifier Protectors: Over Heat-Thermal protector
9. Each module can adjust power, warning standing wave indicator and warning temperature indicator separately.
Jamming Frequency Range
Frequency Band: 20-3000 MHz, Full band jamming-No Gaps
Physical Data
Dimensions:56x48.5x64.5cm
Weight: 50KG(With Power Supplier,Not including betteries)
Environment of operation
Operating Temp: -40 to +65 Celsius Degree
Humidity: 5% - 80%
Optional Accessories
Backup Battery: Yes
If batteries needed,please inform us your requirement of working hours.
Power Division
Frequency Band Output power
1. 20-80MHZ 50 W
2. 80-200MHZ 50 W
3. 200-500MHZ 200 W
4. 500-975MHZ 100 W
5. 975-1450MHZ 50 W
6. 1450-1925MHZ 50 W
7. 1925-2400MHZ 50 W
8. 2400-2500MHZ 50 W
9. 2500-3000MHZ 50 W
14. 930-960MHZ 50 W
15. 1800-1990MHZ 50 W
16. 2110-3000MHZ 50 W
Total 800 W
**Remark :TX Frequency and Each band output power is optional according to your requirments.
Spare Parts:
1. 1 pcs Backup Battery(Optional):
2. 16 Omni Directional Antennas;
3. 16 pieces Cables with length 07 meters Extend to Install Antennas;
Application area
Mainly used in the area of big prison,big ground,battalion as well as illegal congregation,illegal demonstration,military rehearse,special action etc.
Order and Shipping information:
Price terms:EXW price not including custom tax fee,bank transfer fee,buyers are response for it.
Package items:One MOBILE SIGNAL JAMMER kit DZ101H-VIP,15 pieces omni antennas,one power supply,installation screws,one user mannual.
Payment Terms: Paypal,T/T,L/T,Western Union.
Delivery date:Usually 20 working day after receive your deposit.
Min. Order:One charged sample to test quality.
Transportation: DHL,FFEDEX,EMS or According to your special request.
Trademark: Dezhen
Port:Shenzhen China
Import Note:
1.Please contact us whether goods available or not before your order.
2.Please inform us the specifications of the power supply plug you need.
3.We fix the frequency according to your country mobile frequency.If you need special frequency,please inform us.
Warranty & Maintenance:
1.We do our best to serve our each customer the best that we can.
2.We will refund you for items returned within one month with no damage that affects second selling after we send out the goods. A full refund will be given if items are returned in their original condition.Merchandise which is damaged or missing components is not refundable.
3.Three month to replace if quality problem.
4.12 months maintenance warranties.
5.Lifelong technical support.
6.Buyers are responsible for return shipping with proper packaging for warranty items
