Home > Products > casing accessories > self-filling float shoe and float collar
self-filling float shoe and float collar
US$ 500 - 500
/ Set
10 Sets(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | QX | Place of Origin | China | |
| Model Number | 9 5/8\" |
Product Description
FC FLOAT COLLAR
The FC Float Collar is run in a casing assembly, usually several joints above the Float Shoe. It serves as an extra back pressure valve sealing against pressures from blow while running the assembly and after the cementing job. Internal latch and valve are readily drillable. Its capability of back-pressure is over 25MPa.
Specifications
Φ508,Φ339.7,Φ273,Φ244.5,Φ177.8,Φ139.7,Φ127,Φ114.3,Φ101.6,Φ88.9
20",13⅜",10¾",9⅝",7",5½",5",4½",4",3½"
FS FLOAT SHOE
Like the FC Float Collar, the FS float shoe also has a back-pressure valve to prevent back flow. It permits cement to run through side ports when the nose of the shoe is on the bottom. Inner valve and bottom guides are all made of drillable material. Its capability of back-pressure is over 25MPa.
Specifications
Φ508,Φ339.7,Φ273,Φ244.5,Φ177.8,Φ139.7,Φ127,Φ114.3,Φ101.6,Φ88.9
20",13⅜",10¾",9⅝",7",5½",5",4½",4",3½"
