15 DBi 20 * 1500 Omni-directional Fiberglass 2.4 GHZ Wifi Antenna Vertical Polarization
- T/T L/C D/P D/A
- 7 days
You May Like
-
Corrosion Resistance Sector Panel Base Station Vertical Antenna 18 DBi For WCDMA / PCS
-
High Gain 800-2500 MHZ GSM CDMA PCS 3G WLAN Directional Base Station Multiband Antennas
-
Long Range 800 - 2500 MHZ 10.5 - 12 DBi Sector Base Station Directional Panel Antennas
-
High Frequency 2400 - 2500 MHZ 2.4 GHz Base Station WIFI Directional Antennas 18 DBi
-
800 - 2500 MHZ Mimo Dual Polarization Panel Antenna 45 For Data Transmission System
-
GSM / CDMA / PCS / 3G / WLAN System High Gain Multiband Dual Polarization Panel Antenna
Product Details
| Brand Name | Runshine | Place of Origin | China | |
| Model Number | RST-2400-15 |
Product Description
Certification:ROSH
15 dBi Φ20 * 1500 Omni-directional Fiberglass 2.4 GHZ Wifi Antenna Vertical Polarization
Application:
● 2.4 GHz WLAN System
● WIFI telecommunication system
● Point to Multipoint applications
● Wireless AP , wireless adapter
Feature:
● Good appearance
● Durable, corrosion resistance
● Full day for working ,waterproof
● Optimized dimension
● High Gain, Lower VSWR,Strongly Anti-interference
Specification
|
Model NO |
RST-2400-15 |
|
Electric Spec |
|
|
Frequency rang-MHz |
2400～2483 |
|
Bandwidth -MHz |
83 |
|
Gain -dBi |
15 |
|
beam width -° |
H:360 V:5 |
|
VSWR |
≤1.5 |
|
Input Impedance-Ω |
50 |
|
Polarization |
Vertical |
|
Max power -W |
100 |
|
Lightning protection |
DC ground |
|
Connector model |
N Female |
|
Mechanical Specification |
|
|
Size -mm |
Φ20*1500 |
|
Antenna weight-kg |
0.8 |
|
Working Temperature -°c |
-40～60 |
|
Rated Wind Velocity-m/s |
60 |
|
Radome color |
gray |
|
Mounting way |
hold in the pole |
