WLAN WIMAX Repeater / Base Station Omni Fiberglass 5.8GHz Antenna 5725 - 5850 MHz 12 dBi
Application:
● 5.8GHz UNII / ISM frequency
● 5.8GHz WLAN WIMAX system
● Point to Multipoint applications
● Repeater & Base station system
● Signal coverage
Feature:
● Good appearance
● Durable, corrosion resistance
● Full day for working ,waterproof
● Optimized dimension
● High Gain, Lower VSWR,Strongly Anti-interference
Specification
|
Model NO |
RSF-5800-12 |
|
Electric Spec |
|
|
Frequency rang-MHz |
5725-5850 |
|
Bandwidth -MHz |
125 |
|
Gain -dBi |
12 |
|
beam width -° |
H:360 V:7 |
|
VSWR |
≤1.5 |
|
Input Impedance-Ω |
50 |
|
Polarization |
Vertical |
|
Max power -W |
100 |
|
Lightning protection |
DC ground |
|
Connector model |
N Female |
|
Mechanical Specification |
|
|
Size -mm |
Φ20*650 |
|
Antenna weight-kg |
0.46 |
|
Working Temperature -°c |
-40～60 |
|
Rated Wind Velocity-m/s |
60 |
|
Radome color |
gray |
|
Mounting way |
hold in the pole |
