Home > Products > I/O module > KYL-815 24V 4-way wireless io Module 433mhz input output module for 2km-3km valves on-off control
KYL-815 24V 4-way wireless io Module 433mhz input output module for 2km-3km valves on-off control
US$ 75 - 75
/ Piece
2 Pieces(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
KYL-815 433MHZ 4-way Wireless I/O Module for wireless pump control 2km-3km distance ON-OFF Control
-
KYL-815 24V 4 way relay Wireless I/O module to Control ON-OFF Wireless Tank Level
-
KYL-200L 5V 1W Power RF transceivers RS-232/RS-485/TTL 400-470MHz Frequency RF modules 2-3KM LOS
-
KYL-200L rs232 ttl rs485 wireless transceiver 868mhz rf receiver module 2km-3km wireless data transmission for AMR System
-
KYL-200L 868MHz 915Mhz rf module /UHF wireless data transmitter and receiver module 2-3 km FSK modulation RF Module
-
433MHz rf module 2km-3km wireless receiver modules/rf transmitter for wireless telemetry control ttl/RS232/RS485 KYL-200L
Product Details
| Brand Name | KYL | Place of Origin | China | |
| Model Number | KYL-815 |
Product Description
This 4-way ON-OFF module is to transmit the ON-OFF condition to a remote place wirelessly in time. When here the switch condition is ON, the output in the remote place is ON. When the local switch condition is OFF, the other terminal is OFF.
Features:
1. 4-way isolated input, high reliability and stability.
2. 4-way relay dry contact output, contact current is 220V, 5A.
3.Collocated with a wireless data module inside whose transmitting distance is about 2km-3km;
4.the working frequency 433MHz (450 or 470MHz also available ); (pls tell us what frequency you need ? )
5.RF power: 1000mW;
6.Receiving sensitivity: -120dBm
7. Receiving current: 60mA; transmitting current: 350mA
8. Power supply: DC 12V-30V
9.data rate : 1200pbs/2400bps/4800bps/9600bps/19200bps (pls tell us what data rate you need ? )
9. Dimension: 95mm x 90mm x 40mm
Welcome to contact Sarah for more information.
sales01(at)rf-data(dot)com
