Help CenterIndustrial Stainless Steel Pipe Making Machine
Related Products
-
Decorative Stainless Steel Pipe Making MachineNegotiableMOQ: 1 Set -
Square Stainlwss Steel Pipe Surface Polishing MacineNegotiableMOQ: 1 Set
-
Round Stainless Steel Pipe Polishing MachineNegotiableMOQ: 1 Set
-
Mteal Coil Slitting MachineNegotiableMOQ: 1 Set
-
Coconut Oil Press Machine With Filtration Coconut Oil Pressing Machine Coconut Oil Press Machine for Small Business Coconut Oil PressersUS$ 984 - 2984MOQ: 1 Set
1. Industrial stainless steel pipe machine and the applicable materials are:201,202;304'304L,310S,316,316L.321,347H,etc
2. For the production of industrial pipe.
3. One year warranty.
4. ISO9001
Process pipe diameter:
8-219mm
Process pipe thickness:
0.5-5.0.
Application:
Mainly used for the productio of industrial stainless steel pipe.
As the mature technology of stainless steel welded pipe, seamless pipe has been replaced in many areas, such as chemical, pharmaceutical, brewery, oil, food, automotibe, paper and air conditioning industry.
Automated production process:
The open book, cleaning equipment, feed direction, forming, welding, weld the entire inner peace, oter weld grinding, shaping sizing, solution treatment, the final sizing, straightening, testing, marking, set feet, cut off (coil), the materials such as continuous molding process.
Certificate:
All the machines has the certificate of ISO9001:2008.
Warranty:
We provide one year warranty (man-made damage without insurance, the vulnerability of non-insurance).
Machinery main components:
open book machine (uncoiler), forming welding machine, grinding machine, sizing machine, frame straightening, cutting machine, finished frame.
T
echnical parameters:
|
Model |
Horizontal axis diameter (mm) |
Vertical diameter (mm) |
Pipe diameter (mm) |
Pipe thickness (mm) |
Main motor power |
Mechanical assembly size (Length X width |
|
YCG-40 |
40 |
25 |
8-51 |
0.5-2.0 |
Before 7.5 KW After 5.5KW |
29m X 1.5m |
|
YCG-50 |
50 |
30 |
25-63 |
0.5-3.0 |
Before 11KW After 7.5KW |
32m X 1.5m |
|
YCG-60 |
60 |
40 |
50-114 |
0.6-3.5 |
Before 15 KW After 15KW |
35m X 1.8m |
|
YCG-80 |
80 |
50 |
89-168 |
1.0-4.5 |
Before 18.5 KW After 18.5 KW |
40m X 2.5m |
|
YCG-100 |
100 |
60 |
114-219 |
1.0-5.0 |
Before 22 KW After 22KW |
43m X 3.0m |
|
Machinery main components: open-book machine, forming welding machine, grinding machine, two sizing units, straightening frame, cutting machine, finished frame |
