Open loop, semi closed loop CNC system digital AC Servo Driver with 2 axis control

Item

Description

Power supply

 Three-phase AC 220V -15% to +10%  50/60Hz

Output current

Working environment

Temperature

Working temperature: 0-55℃

Storage: -20-80℃

Humidity

Less than 90% (no dew)

Vibration

Less than 0.5 G (4.9 m/S ), 10-60 Hz
(Non-continuous running)

Control mode

Position control

JOG control

Internal speed control

Regenerative braking

Built-in

Character

Speed frequency response

300 Hz or more

Speed fluctuation rate

< ± 0.10% (load: 0-100%, rated voltage)

< ± 0.02% (Power supply: -15-10%, empty load)

Speed regulation ratio

1 : 6000

Input pulse frequency

≤ 500 kHz

Control input

Servo enabling

Alarm clear

Control output

Servo already

Servo alarm

Position control

Input mode

Two-phase A/B positive pulse

Pulse + direction

CCW pulse/CW pulse

Electrical gear

1-32767/1-32767

Feed pulse

A maximum of 25000 pulse/revolution

Acceleration and deceleration

Parameter setting: 1-10000ms (0-2000rpm or 2000-0rpm)

Monitoring function

Speed, current position, command pulse accumulation,
position error, motor torque, motor current, rotor positi
