Home > Products > Cob Led Module > High Efficacy 1920 - 2040 LM 24V 24W Round Cob Led Lighting Module

High Efficacy 1920 - 2040 LM 24V 24W Round Cob Led Lighting Module

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	JD		Place of Origin	China
Model Number	JD-R077080-24V

Product Description

Delivery Time:3-5working days after received deposit.
Certification:CCC, CE, RoHS

High Efficacy 1920 - 2040 LM 24V 24W Round Cob Led Lighting Module

Flat COB LED Module

1. LED chip is fixed on aluminum layer of aluminum base PCB. The heat from chip can be spread out through aluminum layer rapidly.

2. Low lighting decay, decay less than 3% after 1000 hours.

3. Equable and soft irradiancy, no glaring and eye Protection.

4. Good reliability, no dead bulb and no motting.

5. LED full lighting module can be combined into different LED lights easily.

6. Highly Color-rendering index and lighting effect. Safty, Environment friendly.

Applications:

Round full lighting module is widely used for LED bulb, LED cup , LED spot light, LED down light and so on.

Specifications:

Category	Name	Data
Electrical data	Voltage/Current Voltage	DC15-17V/300mA
Voltage	DC24V1000mA
Power Consumption	24W
Luminance Efficiency	80-90LM/W
Luminance data	Luminous flux	1920-2040LM
Color temperature(CCT)	3200K±200K (warm white) 5500K±200K (natural white) 4500K±300K ( cold white) 6000k±300K (day white)
Color rendering index(CRI)	Ra>80
Shell material	Aluminum alloy
Integrated data	Working temperature Ambient temperature	-20°C~60°C
Longevity	≥50000h
Dimensions	Diameter77x3mm
	Luminous Surface Dimension	Diameter63mm

Competitive Advantage:

LED cob lamp surface is fixed on aluminum layer of aluminum base PCB. The heat from chip can be spread out through aluminum layer rapidly.

1. High Lumens:

The lumens of our products can reach up to 75-85Lumen per watt for warm white color and 90-100lumen per watt for white color. It is the first-rate in China even in the World.

2. Equable Lighting:

The lighting surface is a whole part and avoid the glaring one by one lamp so it can protect humen eyes from glaring.

3. Better Heat Dissipation:

The chips are fixed on the aluminum base directly. Due the better dissipation of the aluminum, the heat can be spread out from it quickly so this can lengthen the lifespan of LED.

Competitive Advantage:

LED cob lamp surface is fixed on aluminum layer of aluminum base PCB. The heat from chip can be spread out through aluminum layer rapidly.

1. High Lumens:The lumens of our products can reach up to 75-85Lumen per watt for warm white color and 90-100lumen per watt for white color. It is the first-rate in China even in the World.

2. Equable Lighting:The lighting surface is a whole part and avoid the glaring one by one lamp so it can protect humen eyes from glaring.

3. Better Heat Dissipation:The chips are fixed on the aluminum base directly. Due the better dissipation of the aluminum, the heat can be spread out from it quickly so this can lengthen the lifespan of LED.

Description:

Flat COB LED Module

1. LED chip is fixed on aluminum layer of aluminum base PCB. The heat from chip can be spread out through aluminum layer rapidly.2. Low l
