Application
Widely used in the fields of post office,store,elevator,hospital,school,publishing house and stock exchange where normal voltage is in need,and also can be used in the factories of large and middle-scale industrial and mining corp,it is very much suitable for some important devices and supporting single machine.
Input voltage | Three-phase four-line system phase voltage:220±20%
Please specify when ordering)
(can be selected.Please specify when ordering.) |
Output voltage | Phase voltage:220V Single-phase:220V Line voltage:380V |
Output voltage accuracy | 2-5%(can be adjusted) Frequency:50HZ/60HZ |
Efficiency | ≥98%(Power grade is over 50KVA) |
Ambient temperature | -10~+40°C |
Insulation resistance | ≥2MΩ |
Electric intensity | The voltage for electrical strength and power frequency sinusoidal is 2000V without breakdown and flash over when lasts 1minute |
Overload Capacity | It can last 1 minute at the rated current of two times |
Wave form Distortion | No additional waveform distortion |
Protective function | it offers the protections against over voltage,over current,phase shortage and phase-sequence(The single-phase offers no protection against the phase shortage and phase-sequence)and mechanical failure |
Response speed | ≤1s(in the condition that the external voltage changes is 10 |
