2012Chinaplas Exhibition DW-BFM-3L55 3 layers Plastic Blowing Machine
We are one of the most professional manufacturer of plastic packaging machinery in China, 20 years' rich experience in manufacturing plastic packing machine makes us enjoy more advantage than our competitors.
The picture is about our DW-BFM-3L55 3-layer co-extrusion plastic film blowing machine exhibited on the 2012Chinaplas.
Below is the specification about DW-BFM-3L55:
| A+B+C Three-Layer Co-Extrusion Blowing Film Machine | ||
| Capacity | Model | DW-BFM-3L55 |
| Suitable Material | HDPE / LDPE / LLDPE / EVA | |
| Film Width Range | 800-1300mm | |
| Film Thickness | 0.018-0.2mm | |
| Max Output | 200kg/hr | |
| Extruder Unit | Screw Diameter | AΦ55BΦ65CΦ55 |
| Screw L/D Ratio | L/D 28:1 | |
| Screw Material | 38CrMoALA | |
| Screw Rotation Speed | 25-150r/min | |
| Driving Motor | 100P (A22KW+B30KW+C22KW) | |
| Temperature Control | 3*6Zone | |
| Heating Capacity | 40.5KW | |
| Barrel Cooling Fan | 1/7HP(180W)*9 | |
| Die Head Unit | Die head Diameter | Φ250/300 |
| Blower | 7.5HP(5.5KW) | |
| Heating Capacity | 7.6KW | |
| Temperature Control | 3Zone | |
| Die Head Material | 40Cr | |
| Take-Up Unit | Take-Up Roller Width | 1400mm |
| Effectual Take-Up | 1300mm | |
| Take-Up Motor | 3HP(2.2KW) | |
| Take-Up Line Speed | 80m/min | |
| Winding Unit | Winding Roller Width | 1400mm |
| Effectual Winding | 1300mm | |
| Winding Motor | 3HP(2.2KW) | |
| Total Height | 8500mm |
Optional equipments could be fitted with:
1) Weighing Scales 3 sets
2) Automatic Feeder 3sets
3) Full-automation Double Slitting & Double Winding Unite
4) IBC Inner Cooling System
5) Water Cooling System
6) Upper Rotary
7) Automatic Deviation Rectifying Device
8) Corona Treater
9) Manually Quick Net-Changing Device
10) High power module control
If you are interested, please feel free to contact us at any time.
Professional manufacturer with 20 years’ experience of plastic packing machine: film blowing machine, plastic blowing machine, plastic bags printing machine, T-shirt bag making machine, Garbage bag making machine, Side-sealing machine, Heat-sealing & cutting machine.....
