Certification:CE ROHS
Home Ozone Electric Water Purifier with Water Pressure 10 Psi - 75 Psi
PRODUCT PURPOSE
ECO Laundry is an environmentally friendly appliance intended for using in a residential washing machine.
ECO Laundry is designed to work with your washing machine, mixed active oxygen and silver ions into the water.The processed water can wash clothes cleanly and kill bacteria on clothes without leaving any residual detergent.
ECO Laundryhas the main functions as below:
Sterilization and disinfection;
Decontamination and purification;
Clean and softening;
Energy conservation and environmental protection
The operation of ECO Laundry is easy and convenient. As long as you install ECO Laundry properly, you simply need to operate your washing machine following manufacturer’s operation instructions. ECO Laundry will start working automatically when the washing machine starts to work, and it will automatically turn off when the washing machine stops operation.
TECHNICAL SPECIFICATION TABLE
|
Model |
ECO Laundry(OLK-W-01) |
|
Electrical |
Input: AC 100-240V/50-60Hz Output: DC 12V 3A 36W |
|
Ozone Concentration |
0.4 ~ 0.6 mg /L |
|
Water Pressure |
Minimum:10 psi Maximum:75psi |
|
Operating Temperature |
0℃~78℃ |
|
Product dimension |
417mm×202mm×93mm |
|
Net Weight |
1.75 Kgs |
USE & SAFETY CONSIDERATION
Before using, please read the User’s Manual carefully.
Disconnect ALL power before servicing.
Do not operate the unit with the cover removed.
Maximum water inlet pressure is 75psi.
Use the supplied new hose when connect the ECO Laundry unit to your washing machine. You should replace any existing washing machine hose that is more than 2 years old, with a new one.
To prevent leakage caused by back-flow from the washing machine, do not leave your water hose disconnected. Simply turn the water off at the valve / faucet on the wall, leaving the hose connected.
Use a soft cloth dampened with water. Do not clean your ECO Laundry with harsh chemicals, abrasives or cleansers.
Do not mount the ECO Laundry unit vertically or at an angle.
ECO Laundry is designed for residential use only and is not intended for use in a commercial or industrial setting.
ECO Laundry can work normally in the temperature category 0℃~78℃, without components breakdown.
①Water inlet
②Water Outlet
③Flow Switch
④Venturi
⑤Static Mixer
⑥PCO Cell
⑦Control Module
⑧Oxidizing Module
⑨Mounting Holes
⑩Power Supply
Replacement Parts
|
Part Name |
Part No. |
|
|
⑥ |
PCO Cell |
ECO Laundry-P- PCO |
|
⑦ |
Control Module |
ECO Laundry-P- PCB |
|
⑧ |
Oxidizing Module |
ECO Laundry-P- OM |
INSTALLATION REQUIREMENTS
Electrical Requirements
ECO Laundry requires 120Volt 60Hz power on a 15amp fuse or Circuit Breaker.
A dedicated electrical circuit, equipped with an approved GFCI outlet, is recommended for supplying power to your ECO Laundry.
NEVER use an extension cord or a power adapter other than the one provided with ECO Laundry.
Water Requirements
Water pressure of 10 to 75psi is required to correctly operate your ECO Laundry.
To avoid the possibility of water damage (i.e. a hose leak) it is recommended that you always turn off the water supply valves/faucets when the washing machine is not in use.
Water quality may affect the performance of your ECO Laundry. If you have water quality concerns, such as high content, consu
