100mm Feeding Height Metal CNC Router For Adverting Sign Plate,

Model

CTE 8090A

CTE 1212A

CTE 1218A

CTE 1225A

Table size(mm2)

900×1270

1300×1725

1300×2325

1300×2925

X.Y.Z working area(mm3)

800×900×90

1200×1200×100

1200×1800×100

1200×2400×100

Max rapid traverse

10m

12m

12m

12m

(mm/min)

Max engraving

speed(mm/min)

8m

10m

10m

10m

Mechanical resolution

0.05mm

Repeatability resolution

0.05mm

Max feeding height

100mm

130mm

Motor driver

Micro - step

Power consumption/

300

without spindle(w)

Spindle/clamp(KW)

1.2 KW/ф6, ф3.175

1.5 KW/      ф6, ф3.175

2.2 KW/ ф6, ф3.175

rotation speed(rpm)

600-24000

controller

DSP 100HZ

Software working

WINDOWS98/2000

interface

USB

Protocol

3D protocol(HP-GL, G-code)

Memory storage

32M flash memory

Operation environment

temperature:+5℃~+35℃;relative humidity:30%-7

Power voltage

AC220V±10% 50HZ

Weight(KG)

260

550

680

810

Dimension(mm3)

1405×1151×1200

1825×1550×1250

2425×1550×1250

3025×1550×1250
