Air-cooling 6100

 Detailed Product Description

air-cooling,generator,pump,truck,

Engine Model                                                           6100
Piston No.& Arrangement                                      6-Cylinder Inline
Bore/Stroke                                                               100/120
Capacity (L)                                                               5.655
Cooling & Stroke                                                      Air-cooled2-Stroke
Air Intake                                                                    Natural Aspirated Rated
Power/Rev (km/rpm)                                               48/1500
Dimension    Length/Width/Height(mm)             1120*673*815
Weight (Kg)                                                                410

Engine Model                                                            6100
Piston No.& Arrangement                                       6-Cylinder Inline
Bore/Stroke                                                                100/120
Capacity (L)                                                                5.655
Cooling & Stroke                                                       Air-cooled2-Stroke
Air Intake                                                                     Natural Aspirated Rated
Power/Rev (km/rpm)                                                60/1800
Dimension    Length/Width/Height(mm)              1120*673*815
Weight (Kg)                                                                410

Engine Model                                                            6100
Piston No.& Arrangement                                       6-Cylinder Inline
Bore/Stroke                                                               100/120
Capacity (L)                                                                5.655
Cooling & Stroke                                                       Air-cooled2-Stroke
Air Intake                                                                     Natural Aspirated Rated
Power/Rev (km/rpm)                                                74/2300
Dimension    Length/Width/Height(mm)              1120*673*815
Weight (Kg)                                                                410

Engine Model                                                             6100
Piston No.& Arrangement                                       6-Cylinder Inline
Bore/Stroke                                                                100/120
Capacity (L)                                                                5.655
Cooling & Stroke                                                       Air-cooled2-Stroke
Air Intake                                                                     Natural Aspirated Rated
Power/Rev (km/rpm)                                                78/2500
Dimension    Length/Width/Height(mm)              1120*673*815
Weight (Kg)                                                                410


Performance                             Max. Power(kw/bhp)                       82KW
Performance                             Rated Rev(r/min)                            1500-2500
Performance                             Max. Torque(N.m)                           345
Performance                             Max. Torque/Rev(r/min)                 1600r/min
Performance                             Emission
Physical Parameter                 Diesel Engine Model                     6100
Physical Parameter                 No. of Cylinder                                 6
Physical Parameter                 Intake System                                  Natural Aspirated Rated
Physical Parameter                 Capacity                                            5.655L
Physical Parameter                 Bore/Stroke(mm)                            100*120
Physical Parameter                 Ignition Sequence                          1-5-3-6-2-4
Physical Parameter                 Cooling Media                                 Air
Physical Parameter                 Injection                                            Direct Injection
Physical Parameter                 Compression Ratio                       17:1
Physical Parameter                 Rotation                                            Clockwise
                                                                                                                (Viewed  From Fan Side)
Physical Parameter                 Power Output                                   Flywheel
Physical Parameter                 Net Weight(kg)                                410
Physical Parameter                 Length(mm)                                    1120
Physical Parameter                 Width(mm)                                       673
Physical Parameter                 Height(mm)                                     815
Physical Parameter                 1. The final dimension depends on the spec of
                                                      fully assembled engines
Physical Parameter                  2. These weights for units without fan, flywheel,
                                                     flywheel housing and starter motor are estimated only.
