Home > Products > Fiber Optic Media Converter > 14/16 Slot Media Converter Rack For Converter Card
14/16 Slot Media Converter Rack For Converter Card
- T/T L/C D/P D/A
- 7 days
You May Like
-
Standard SC type Single mode Duplex Fiber Optic Adapter
-
10/100M 4 RJ45 Prots And 1 Fiber Port managed Fiber Optic Switch
-
Low Insertion Loss ST type Multi-mode Simplex Fiber Optic Adapter
-
Multi-mode And Single-mode fiber 10/100M 1-Port FX + 4-Port TP Managed Fiber Switch
-
ST type Single mode Simplex Fiber Optic Adapter
-
10/100M 1-Port FX + 7-Port TP Fiber Switch (External Power Supply)
Product Details
| Brand Name | Fiberroad | Place of Origin | China | |
Product Description
The configuration of active/standby power supply ensures uninterruptible operation of the system. Provide two power supplies (AC 220V, and DC -48V), enabling the system can work under many operating environments; Supporting simultaneous operation of several module type (module type) media converters at different rates, which greatly improves system adaptability; Each card supports hot swapping;
Technical Indexes Description:
|
Parameter |
Specifications |
|
|
Number of slots |
16 |
14 |
|
Structure |
2U rack |
2U rack |
|
Power input |
AC Voltage: AC 85~265V; frequency: 50/60 Hz |
AC Voltage: AC 85~265V; frequency: 50/60 Hz |
|
DC voltage: DC-36~72V |
DC voltage: DC-36~72V |
|
|
Power output |
DC5V 16A |
DC5V 16A |
|
Ripple |
<20mv |
<20mv |
|
Power configuration |
Single power supply; or Dual power supply for warm backup mode |
Single power supply; or Dual power supply for warm backup mode |
|
LED indication |
POWER (power supply) |
POWER (power supply) |
|
Max. power consumption |
80W |
80W |
|
Operating temperature |
-10~55ìC |
10~55ìC |
|
Operating humidity |
5%~90% |
5%~90% |
|
Maintaining temperature |
-40~70ìC |
-40~70ìC |
|
Maintaining humidity |
5% ~ 90% non-condensing |
5% ~ 90% non-condensing |
|
Dimensions of rack |
90mm (H) * 485mm (W) * 245mm (D) |
88mm (H) * 442mm (W) * 350mm (D) |
Order information:
|
Model No |
Description |
|
FR-R 14A |
14-slot dual-power supplies rack (220v) |
|
FR-R14D |
14-slot dual-power supplies rack (-48v) |
|
FR-R 16A |
16-slot dual-power supplies rack (220v) |
|
FR-R16D |
16-slot dual-power supplies rack (-48V) |
