Key features of KSAP0121200100HE-H
●Light, extra slim, sleek, compact design
●Green power, full complies with CEC level V, MEPS IV EUP2011
●High power density
●Extra safe design, have got their respective safety approvals
●Completed protect function
Key Applications ofKSAP0121200100HE-H
It’s suitable for an extremely wide range of applications, including:
●Mobile Devices
●ADSL
●Pos
●Audio & Video product
●Household appliance
●Set-top-box
●Input Voltage: 90 to 264 VAC
●Frequency : 47-50/60-63hz
●Input current :0.4A(Max) 120 /240VAC
●Inrush current:60AMax. 120VAC at max Load
100AMax 240VAC at max Load
●Leakage current : 0.25 mA Max
●Over voltage protection
●Over current protection
at 250% of lo and Auto-recovery
●Electronic short circuit protection
●Operatingtemperature 0~40℃Free convection
●Operating humidity 10-90% RH Non Condensing
●Sea level Non-operating temperature -20~80℃
●Information technology equipment
●IEC/EN 60950-1, UL 60950-1, CSA C22.2
No. 60950-1-03
●CB , CE
●Radiation Test&Conduction Test:EN 55022/FCC Part 15
●Harmonic Test : EN 61000-3-2
●Flicker Test : EN 61000-3-3
●ESD Test:EN 61000-4-2
●RS Test:EN 61000-4-3
●EFT Test:EN 61000-4-4
●Surge Test:EN 61000-4-5
●CS Test:EN 61000-4-6
●DIP Test:EN 61000-4-11
|
Dimension L*W*H (mm) : 82 * 43.5 * 31 |
