Home > Products > Roll Forming Machinery > 380V / 50HZ Steel Slitting Lines Machine for Zinc-plating Roll Sheet
380V / 50HZ Steel Slitting Lines Machine for Zinc-plating Roll Sheet
- 0 Meter / Meters per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Wall Panel Steel Sheet Roll Forming Machine in Construction for Outdoor Decoration
-
Roof and Wall Panel Roll Forming Machine with 18 Groups of Roller Station
-
Wall Panel Roll Forming Machine with Touch Screen PLC Control System for Construction
-
Trapezoid Roof Panel Forming Machine with Chain Transmission for Greenhouses
-
5.5kw Hydraulic Cutting Roof Panel Roll Forming Machine with for Outdoor Decoration
-
5.5kw Roofing Sheet Roll Forming Machine with + / - 0.5mm Cutting Length Tolerance
Product Details
| Brand Name | DB | Place of Origin | China | |
| Model Number | According to profile |
Product Description
Certification:CE
380V / 50HZ Steel Slitting Lines Machine for Zinc-plating Roll Sheet
Consist of the slitting line
COIL CAR
UNCOILER
HOLD DOWN ROLL
LEVELER
SHEAR
SIDE GUIDE
SLITTER
SCRAP WINDERS
LOOP TABLE
TENSION STATION
SEPARATOR
RECOILER
Descriptions:
Components of the 1300 semiautomatic slitting line: coil car, hydraulic decoiler, slitter, hydraulic tension station, hydraulic recoiler
Main parameters:
Size(mm):20000*6000*2000
Material: common carbon steel sheet, zinc-plating roll sheet, stainless steel sheet
Material quality: steel coil
Thickness(mm): 0.2-1.5
Width(mm): 1250
Coil I.D(mm): f508
Coil O.D(mm): f1500
Coil weight: 11t(max)
Slitting product:
Coil I.D: f508mm
Slitting tolerance thickness:1.0mm?.03mm(max)
Slitting burr thickness: 1.0mm=0.03mm(max)
Minimal width :12mm
Slitting number: 20(coil thickness 0.5mm)
16(coil thickness1.5mm)
Electric power: 380V/50HZ/3PH
Capacity: 100KW
Speed: 0-80m/min
Slitting type: rolling shear
