LiSOCl2 Battery ER26500 ERC 3.6V With Stable Operation Voltage

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

Tac

Place of Origin:

China

Model Number:

ER26500

Hong Kong Tac Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name Tac

Place of Origin China

Model Number ER26500

Delivery Time:7days after order
Certification:UL,ROHS

LiSOCl2 Battery ER26500 ERC 3.6V with Stable Operation Voltage

Description:

1. High energy density: the battery can reach 420WH/KG and 800WH/dm3

2. High voltage: open circuit voltage of 3.65V, voltage range of 3.3V to 3.6V that is changed with the change of the load,

the end voltage is 2.0V or 2.5V.

3. Stable operation voltage: excellent stability. On the high voltage platform where the voltage is almost unchanged,

the capacity output is still more than 90%.

4. Wide temperature range: provide the widest temperature range among all existing batteries from -60℃ to 85℃

5. Excellent storage life: annual self-discharge rate is less than 1%. Fully-sealing structure and self-life is more than

10 years under room temperature.

Application:

*Intelligent water meter, Ammeter, Gas Meter

*Industrial PC computer, Computer RAM, CMOS Memory Backup Power Sources

*Medical Instruments, Radio Communication, Seismic Equipment, Digitally-controlled Machine, Taxi Meter, Telephone

*Underwater Weapon, Military Communication Transmitter-receiver, Portable communication Equipment, RMPS and more.

Packing Method:

70PCS/layer, 700Pcs/Carton, Weight: 20KG Size:44*27*33cm

Specification:

No	Item	Data
1	Nominal voltage:	3.6V
2	Nominal capacity:	9000mAh(2mA / 2.0V)
3	Discharge end-voltage:	2.0V
4	Operating voltage :	3.4V(330Ω, in 5s)
5	Max constant discharge current:	200mA
6	Max. pulse current:	400mA
7	Ambient temperature range:	-55~ +85℃
8	Storage life:	≥10 year, Yearly self-discharge ≤ 1%
