Sell Drilling Machine

Model No.:SP3106
Product Origin:China
Brand Name:
Price Terms:
Payment Terms:
Certification:
Description:Specifications: 1) Max. drilling diameter: 35mm 2) Max. travel of spindle: 190mm 3) Max. distance from spindle nose to generating line of column: 340mm 4) Max. distance from spindle nose to surface of worktable: 665mm 5) Max. distance from spindle nose to surface of base worktable: 1,195mm 6) Max. travel of worktable and bracket: 570 (450)mm 7) Swivel angle of worktable: ±45 degrees 8) Spindle taper bore: mt4 9) Spindle speed steps: 12 10) Spindle speed range: 76-2,605 11) Spindle feed steps: 3 12) Spindle feed range: 0.1, 0.2, 0.3 13) Dimension of worktable: 520 x 440 14) Effective working area of worktable: 405 x 395 15) Diameter of column: 140mm 16) Power of motor: 1.5kW 17) Machine dimensions: 849 x 545 x 2,290mm 18) Mode of spindle feed: mechanical / electromagnetism Conveyance: Qty/20' FCL: 30 sets
