P12 Outdoor Full Color Led Illumination Display Panel 2R1G1B With IP65 CE & RoHS

SBO-P12 (Pitch 12mm outdoor full color-1/2 scan)

Colour temperature

5000~9000 k

Pixel structure

φ3 oval lamp, 2R1G1B

Pixel pitch

12mm

Pixel density

6, 944 dots/㎡

Luminance

7, 000cd/㎡

Module dimension

192mm(W) * 192mm(H)

Module resolution

16 pixel(W) * 16 pixel mm(H)

Cabinet dimension

1152 * 768mm

Cabinet resolution

96 * 64

Cabinet area

0.885 sq. meter

Optimal visual distance

>12m

Visual angel

110 / 50 degree (H/V)

Max power consumption

≤1100w / ㎡

Average power consumption

≤700w / ㎡

Brightness adjustment

Adjust according to the environment

brightness software (0%-100%adjustable)

Gray scale

point by point 4096 gray grade levels of

each color, 16 bits γ correction available

Drive mode

1/2 dynamic scan, constant current

Frame frequency

≥60HZ

Refresh frequency

≥480HZ

Input voltage

AC 90~260 volts

Operation temperature

﹣40℃~ +65℃

Operation humidity

10％～90％

Input signal

S-video, RF, RGB, Yuv, YC, composite…

Control system

DVI card + master control card + receiver card

MTBF

>5000 hrs

Life span (50% brightness)

100, 000 hrs

Malfunction dot rate

1/10000

Ingress protection rate (Front/ rear)

IP65 / IP54

Cabinet material

Epoxy paint coated, aluminum / iron

Application:
