P10 Outdoor Full Color Shopping Mall Led VideoBillboard Display Wall With Density 10,000

SBO-P10 (Pitch 10mm outdoor full color-1/4 scan)

Colour temperature

5000~9000 k

Pixel structure

φ3 oval lamp, 1R1G1B

Pixel pitch

10mm

Pixel density

10, 000 dots/㎡

Luminance

7, 500cd/㎡

Module dimension

160mm(W) * 160mm(H)

Module resolution

16 pixel(W) * 16 pixel mm(H)

Cabinet dimension

1280 * 960mm

Cabinet resolution

128 * 96

Cabinet area

1.229 sq. meter

Optimal visual distance

>10m

Visual angel

110 / 50 degree (H/V)

Max power consumption

≤1200w / ㎡

Average power consumption

≤750w / ㎡

Brightness adjustment

Adjust according to the environment

brightness software (0%-100%adjustable)

Gray scale

point by point 4096 gray grade levels of

each color, 16 bits γ correction available

Drive mode

1/4 dynamic scan, constant current

Frame frequency

≥60HZ

Refresh frequency

≥480HZ

Input voltage

AC 90~260 volts

Operation temperature

﹣40℃~ +65℃

Operation humidity

10％～90％

Input signal

S-video, RF, RGB, Yuv, YC, composite…

Control system

DVI card + master control card + receiver card

MTBF

>5000 hrs

Life span (50% brightness)

100, 000 hrs

Malfunction dot rate

1/10000

Ingress protection rate (Front/ rear)

IP65 / IP54

Cabinet material

Epoxy paint coated, aluminum / iron

Application:
