60led/m non-waterproof SMD 3528 Flexible blue led Strip, 4.8w/m, 5m/reel, R/G/B/Y/WW/W/CW availab

Name: 60led/m non-waterproof SMD 3528 Flexible blue led Strip, 4.8w/m, 5m/reel, R/G/B/Y/WW/W/CW availab
Brand: ketaixing
Price: Negotiable

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment Terms:T/T L/C D/P D/A
Delivery Detail:7 days

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:

ketaixing

Place of Origin:

China

Product Description

Delivery Time:sample within 3 days,big order between 10-20 days
Certification:CE,Rohs,FCC

60led/m non-waterproof SMD 3528 Flexible blue led Strip, 7.2w/m, 5m/reel, R/G/B/Y/WW/W/CW available

Features:

The thickness of the wires should be adopted based on the possible maximum current, length of wires(10m in maximum is recommended)and the loss in the wires during transit at low voltage Two ends of connection should be done as waterproof No touch in static, no work in electricity The maximum length is 5m, no exceeding in connection Quality power supply is recommended(with short circuit protection, high voltage and power load protection) It can be cut at the mark of the connection and there will be no affect to its function

Main Technology Index:

Specification
LED type	3528 SMD LED
Available colors	W/M/R/G/B/Y
Viewing angle(θ)	120°
Luminous flux (lm)
R G B Y WW W CW
330 900 270 300 1500 1500 1500
Wavelength (nm/K)
R G B Y W WW CW
619-635 512-528 463-475 584-595 5500-6500 2700-3000 8000-11000
LED Q'ty / 5meters	300pcs
Life span	50, 000h
Electric parameter
Working voltage(V)	DC 12V
Power consumption(W)	24W
Driving method	Constant voltage
Wires&series connection length
Wires Input end connect two-core red and black wire, Red:+;Black:-
Stand length in serial connection	5m
Maximum length in serial connection	≤5m
Outer Parameter
Shell	Clear PVC inject epoxy
PCB Color	Amber / white
Dimension	L 5000mm * W 8mm * H 2.2mm
Fixed mode
Screw	/
Double-side adhesive	5000*8mm, 3Mdouble-sided adhesive with mounting clips
Environment Parameter
Working Temperature	-40℃- +50℃
Storage Temperature	-50℃- +60℃
IP grade	IP33

Application:

Widely for : Architectural decorative lighting , Amusement park, Theater and aircraft cabin moodlig
